Molex KK 254 Series Right Angle Through Hole Pin Header 16 Contact 2.54 mm Pitch 1 Row Unshrouded 22-05-3161

Molex 22-05-3161 KK 254 Series Right Angle Through Hole Pin Header is a high-quality connector designed for electronics applications requiring secure wire-to-board connections. Featuring 16 brass contacts with tin plating, and a durable nylon UL 94V-0 white housing, this header ensures reliable electrical performance and mechanical strength.

Designed with a right-angle orientation and through-hole mounting style, the connector integrates easily with printed circuit boards for diverse industrial and commercial electronics assemblies. Its unshrouded design facilitates straightforward solder termination and wire contact access.

The pin header supports 4A current and 250V voltage ratings, enabling usage in power and signal applications within electronics manufacturing, industrial control systems, and related sectors. Its operational temperature range from -40°C to 105°C makes it suitable for varied environmental conditions.

Individual contact tail pins are 3.58 mm long, providing adequate insertion depth for solder joints. This product series mates seamlessly with the KK 254 series housings featuring friction locks, allowing end-to-end stacking and modular connector assembly.

The connector system is designed for wire-to-board applications, offering robust electrical contact material properties with brass construction and tin plating for corrosion resistance and conductivity.

This pin header offers a current rating of 4A and operates up to 250V. Constructed with a nylon housing and brass contacts with tin plating for robust electrical performance. Designed with a right-angle orientation and through hole mount for PCB integration.

Tail pins measure 3.58 mm in length and the connector supports a temperature range of -40°C to 105°C. Termination type is solder and the header is unshrouded, allowing easy access to contacts. Suitable for industrial, electronics manufacturing, and power connector applications.

The product complies with standard commercial voltage and temperature ratings for PCB connectors. Mates with compatible KK 254 series housings with friction lock features. Ideal for wire-to-board assembly requiring reliable mechanical and electrical connections.

This Molex pin header supports industrial, manufacturing, electronics assembly, and power electronics use cases, making it a versatile component in PCB and connector solutions. Environmental and operational reliability are ensured by compliance with common commercial standards.
