Molex 16-Way IDC Connector Male for Surface Mount, 1 Row, 1.2A, 250V ac, Picoflex Series 90814-0816
Specifications
| Country of Origin | Ireland |
|---|---|
| Voltage | 250, 250V ac |
| Brand | Molex |
| Orientation | Straight |
| Current | 1.2A |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Picoflex |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 16 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| 90814-00xx | SMT, Tin, with PCB pegs |
| 90814-06xx | SMT, Tin, no PCB pegs |
| 90814-07xx | SMT, Tin, no PCB pegs |
| 90814-08xx | SMT, Tin, with PCB pegs |
| 90814-09xx | SMT, Tin, with PCB pegs |
| 90814-38xx | SMT, Gold flash, with PCB pegs |
| 90814-39xx | SMT, Gold flash, with PCB pegs |
| 90325-00xx | Through hole, Tin, with PCB pegs |
| 90325-90xx | Through hole, Tin, with PCB pegs |
| 93405-05xx | Reverse footprint, SMT, Tin, no PCB pegs |
Key Features
- Supports 16 contacts arranged in a single row for compact design.
- Rated current of 1.2A and voltage of 250V ac for efficient power handling.
- Features a 1.27mm pitch suitable for high-density PCB applications.
- Male connector with straight orientation and unshrouded design for easy mating.
- Contact plating is tin over nickel providing corrosion resistance.
- Constructed with brass contacts and nylon housing for durability and insulation.
- Termination type is Insulation Displacement Contact (IDC) for fast, reliable assembly.
- Operating temperature ranges from -40°C to 105°C ensuring stable performance.
Product Description
Molex 90814-0816 IDC Connector Male is a 16-way, single-row surface mount connector from the Picoflex series designed for reliable and compact wire-to-board connectivity in demanding electronic applications.
Featuring a 1.27mm pitch and a maximum current rating of 1.2A at 250V ac, this male connector is suitable for automotive, consumer electronics, and industrial electronics where space saving and high density are critical. Its unshrouded contacts with tin over nickel plating ensure excellent conductivity and corrosion resistance.
The connector uses Insulation Displacement Contact (IDC) termination for efficient assembly and is housed in durable nylon with brass contacts to withstand mechanical and environmental stresses. Its straight orientation and friction lock with polarization features simplify installation and ensure secure mating.
Operating reliably from -40°C up to 105°C, it meets the requirements of various industrial standards and applications including electronic components, power connectors, and PCB housings.
16 contacts in a single row arrangement for high-density connection. Rated for 1.2A current and 250V ac voltage operation. 1.27mm pitch Picoflex headers supporting reduced space requirements. Surface mount type ideal for PCB assembly with robust mechanical retention.
Durable brass contacts with tin over nickel plating for longevity. Unshrouded, male contacts with straight orientation. Wide temperature operating range from -40°C to 105°C. Made with nylon housing for insulation and strength.
Manufactured in Ireland ensuring strict quality control.
This IDC connector is widely used in industries such as electronics manufacturing, automotive systems, consumer devices, and electrical control equipment, providing secure and efficient connections where space and reliability are paramount.
Explore more IDC Connectors and related electronic components at EnvMart to meet diverse application needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector is rated for a maximum current of 1.2A and a voltage of 250V ac.
It features a pitch of 1.27mm, making it suitable for high-density PCB applications.
The connector is constructed with brass contacts and a nylon housing, providing insulation and strength.
This model has 16 contacts arranged in a single row.
It uses Insulation Displacement Contact (IDC) termination for fast and reliable assembly.
The operating temperature range is from -40°C to 105°C, ensuring stable performance in various conditions.
The connector has a straight orientation with unshrouded contacts for easy mating.
It is manufactured in Ireland, ensuring strict quality control.
This IDC connector is suitable for automotive, consumer electronics, and industrial electronics applications.
This model is designed for surface mounting, ideal for PCB assembly.
The contacts are plated with tin over nickel, providing corrosion resistance.
There are several variations within the Picoflex series, including options with and without PCB pegs and different plating types.
