Molex C-Grid III Series Straight Through Hole Pin Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0923

Free Delivery in India | Lowest Global Shipping Charges

Molex C-Grid III Series Straight Through Hole Pin Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0923

Name: Molex C-Grid III Series Straight Through Hole Pin Header, 3 Contacts, 2.54 mm Pitch, 1 Row, Unshrouded 90120-0923
Brand: Molex
SKU: 207031
Price: 2.1 USD
Availability: InStock



Category PCB Pin Header Brand Molex Condition New

Specifications

Country of Origin	India
Voltage	350V
Brand	Molex
Orientation	Straight
Current	3A
Mount Type	Through Hole
Housing Material	Polyester
Contact Material	Brass
Series	C-Grid III
Termination Type	Solder
Maximum Operating Temperature	125°C
Minimum Operating Temperature	-55°C
Number of Rows	1
Pitch	2.54mm
Contact Plating	Gold
Number of Contacts	3
Contact Gender	Male
Shrouded/Unshrouded	Unshrouded
Connector System	Wire-to-Board
Tail Pin Length	2.9mm
Mating Pin Length	6.75mm

Key Features

Features a 2.54 mm pitch and a single row configuration for precise board placement.
Constructed with brass contacts plated in gold for superior conductivity and corrosion resistance.
The housing is made of durable polyester to withstand industrial operating conditions.
Designed for through-hole mounting with a straight orientation and unshrouded connector for easy access.
Operates reliably between -55°C and 125°C, suitable for demanding environments.
Supports a current rating of 3A and voltage rating up to 350V for versatile applications.
Tail pin length is 2.9 mm, with mating pin length of 6.75 mm to ensure secure connections.
Breakaway design allows for size customization, adding design flexibility.

Product Description

Molex 90120-0923 C-Grid III Series Straight Through Hole Pin Header is designed to provide secure and stable wire-to-board connections for electronic components. This pin header features 3 male contacts with a 2.54 mm pitch arranged in a single row and an unshrouded design, making it ideal for various industrial, computer, medical, consumer, telecommunications, and transportation electronic applications.

The pins are constructed from brass with gold plating ensuring excellent electrical conductivity and corrosion resistance. The polyester housing offers robust insulation and durability to withstand harsh operating conditions. Its through-hole mount type and straight orientation allow ease of soldering and mechanical stability on printed circuit boards.

Operating reliably within a temperature range of -55°C to 125°C, this connector supports a current rating of 3A and a voltage rating up to 350V. The breakaway design enables users to cut the header to length, enhancing design flexibility for custom PCB layouts.

This pin header is highly suited for environments requiring stable and durable interconnects such as desktop PCs, servers, medical devices, industrial equipment, telecommunications, and automotive safety electronics.

Features a 2.54 mm pitch and 3 male contacts for precise connections. Brass contacts with gold plating provide superior conductivity and corrosion resistance. Polyester housing ensures durability and electrical insulation.

Straight, unshrouded design with through-hole mounting for easy installation. Temperature range from -55°C to 125°C for versatile industrial use. Breakaway design allows custom sizing on the PCB. High mechanical stability once soldered for reliable long-term performance.

This product belongs to the C-Grid III series, known for its versatility and high-performance wire-to-board and board-to-board applications. It is a trusted choice for engineers designing reliable electronics interconnections.
