Molex 5558 Series Male Crimp Terminal 16 AWG, Brass with Gold Plating, 9A Current Capacity 39-00-0096
Specifications
| Country of Origin | United States |
|---|---|
| Brand | Molex |
| Current | 9A |
| Gender | Male |
| Contact Material | Brass |
| Series | 5558 |
| Termination Type | Crimp |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| For Use With | Mini-Fit Jr Connector Housing |
| Contact Plating | Gold |
| Maximum Wire Size mm² | 1.3mm² |
| Minimum Wire Size AWG | 16AWG |
| Maximum Contact Resistance | 10mΩ |
Key Features
- Designed for use with Mini-Fit Jr connector housings for secure electrical connections.
- Gold-plated brass contact enhances conductivity and corrosion resistance.
- Supports a maximum current of 9 amperes.
- Crimp termination type ensures mechanically stable wire connections.
- Operates within -40°C to 105°C temperature range for versatile application.
- Low maximum contact resistance of 10 mΩ.
- Compatible with standard hand crimp tools for assembly.
- Rated for voltages up to 600V in electrical circuits.
Product Description
Molex 39-00-0096 is a male crimp terminal from the 5558 Series, engineered for Mini-Fit Jr connector housings. It is designed to accommodate 16 AWG wire with a maximum cross-sectional area of 1.3 mm², providing reliable electrical connectivity. Constructed from durable brass and featuring selective gold plating, this terminal ensures enhanced conductivity and resistance to oxidation.
This crimp terminal supports electrical currents up to 9 amperes and functions effectively within temperature limits from -40°C to 105°C, making it suitable for use in diverse industrial, electrical, and automation settings. The low maximum contact resistance of 10 milliohms minimizes energy loss during operations.
Its crimp termination style facilitates secure wire attachment, which is compatible with standard hand crimping tools, easing assembly processes. Rated up to 600 volts, this terminal meets the requirements of demanding electrical systems.
Applications include power supply connections, wire-to-wire linking in automation projects, and use in various electrical devices and systems needing reliable and durable connectors. The product is manufactured in the United States, assuring quality and consistency.
Designed for use with Mini-Fit Jr connector housings for secure electrical connections. Gold-plated brass contact enhances conductivity and corrosion resistance. Supports a maximum current of 9 amperes. Crimp termination type ensures mechanically stable wire connections.
Operates within -40°C to 105°C temperature range for versatile application. Low maximum contact resistance of 10 mΩ. Compatible with standard hand crimp tools for assembly. Rated for voltages up to 600V in electrical circuits.
This Molex crimp terminal is ideal for industrial electrical applications, HVAC systems, manufacturing setups, automated machinery, and other environments where reliable electrical connections are critical. Explore more high-quality connectors and terminals on EnvMart to enhance your electrical projects.
Explore more products in our Crimp Contacts category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This crimp terminal supports a maximum current of 9 amperes.
It operates effectively within a temperature range of -40°C to 105°C.
The terminal utilizes a crimp termination type, ensuring mechanically stable wire connections.
It is designed for use with Mini-Fit Jr connector housings.
The contact material is brass, which is gold plated to enhance conductivity and corrosion resistance.
The maximum contact resistance is 10 milliohms.
This terminal accommodates 16 AWG wire, with a maximum cross-sectional area of 1.3 mm².
It is rated for voltages up to 600 volts in electrical circuits.
Yes, it is compatible with standard hand crimp tools for assembly.
This product is manufactured in the United States, assuring quality and consistency.
It is suitable for power supply connections, wire-to-wire linking in automation projects, and various electrical devices and systems requiring reliable connections.
This terminal belongs to the Molex 5558 Series.
