Molex 26-Way IDC Connector Male for Surface Mount, 1 Row, 1.2A Current, 250V AC, Picoflex Series 90814-0926
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 250, 250V ac |
| Brand | Molex |
| Orientation | Straight |
| Current | 1.2A |
| Mount Type | Surface |
| Housing Material | Nylon |
| Contact Material | Brass |
| Series | Picoflex |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 26 |
| Contact Gender | Male |
| Connector Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| 90814-00xx | SMT, Tin, with PCB pegs |
| 90814-06xx | SMT, Tin, no PCB pegs |
| 90814-07xx | SMT, Tin, no PCB pegs |
| 90814-08xx | SMT, Tin, with PCB pegs |
| 90814-09xx | SMT, Tin, with PCB pegs |
| 90814-38xx | SMT, Gold flash, with PCB pegs |
| 90814-39xx | SMT, Gold flash, with PCB pegs |
| 90325-00xx | Through hole, Tin, with PCB pegs |
| 90325-90xx | Through hole, Tin, with PCB pegs |
| 93405-05xx | Reverse footprint, SMT, Tin, no PCB pegs |
Key Features
- Features 26 contacts arranged in a single row for PCB connection.
- Supports a maximum operating voltage of 250V AC.
- Constructed with brass contacts plated with tin over nickel for corrosion resistance.
- Terminated using Insulation Displacement Contact (IDC) technology for quick assembly.
- Housing made from durable nylon material ensuring insulation and mechanical strength.
- Operates reliably between -40°C and 105°C temperature range.
- Designed for surface mount applications with a straight orientation.
- Unshrouded male connector type with friction lock and polarization features.
Product Description
Molex 90814-0926 is a high-quality 26-way IDC male connector from the Picoflex series designed for surface mounting on printed circuit boards. Operating at 1.2 amps and up to 250 volts AC, it delivers compact and reliable connections with a fine 1.27 mm pitch, ideal for high-density electronics applications.
The connector incorporates unshrouded brass contacts with a tin over nickel plating, housed in a robust nylon case. Its IDC termination type enables efficient cable assembly without soldering, offering both time and cost savings in manufacturing.
This connector operates within the temperature range of -40°C to 105°C, making it suitable for harsh industrial and automotive environments. A straight orientation and friction lock mechanism ensure secure mating and polarization, preventing misalignment during installation.
Widely used in automotive, consumer electronics, and other industrial applications, the Picoflex PF-50 series connectors provide excellent vibration and shock resistance, low profile design, and 50% space savings compared to traditional connectors.
The 90814-0926 variant supports a variety of subseries featuring SMT and through-hole mounting, with or without PCB pegs, and options for tin or gold flash plating, offering designers flexible integration choices.
Features 26 contacts arranged in a single row for PCB connection. Supports a maximum operating voltage of 250V AC. Constructed with brass contacts plated with tin over nickel for corrosion resistance. Terminated using Insulation Displacement Contact (IDC) technology for quick assembly.
Housing made from durable nylon material ensuring insulation and mechanical strength. Operates reliably between -40°C and 105°C temperature range. Designed for surface mount applications with a straight orientation. Unshrouded male connector type with friction lock and polarization features.
Ideal for automotive and consumer electronic applications requiring compact, high-density connections. Supports various SMT and through-hole mounting options across the 90814 series. Explore more IDC Connectors and Picoflex series products at EnvMart for reliability and performance in industrial and electronic design needs.
