Molex C-Grid Series Right Angle Through Hole PCB Socket 4-Contact 1 Row 2.54 mm Pitch Solder Termination 12A 350V 90148-1204
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Bronze |
| Series | C-Grid |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Socket Strip |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 4 |
| Contact Gender | Female |
| Connector System | Signal, Board-to-Board |
Key Features
- Features 4 contacts arranged in a single row with a 2.54 mm pitch.
- Constructed with polyester housing and bronze female contacts for durability.
- Rated for 12 amperes current and 350 volts voltage operation.
- Gold-plated contacts ensure reliable signal connections and corrosion resistance.
- Designed for solder termination with right angle orientation for PCB mounting.
- Operates reliably within temperature range -55°C to 125°C.
- Compatible with 0.64 mm square pin headers including Molex 90120 series.
- Ideal for board-to-board signal connector system in electronic devices.
Product Description
Molex 90148-1204 is a high quality C-Grid Series PCB Socket featuring a right angle through hole design with 4 female contacts arranged in a single row at a 2.54 mm pitch. This connector is engineered for reliable board-to-board signal connections in demanding electronic applications. The housing is made from robust polyester material, providing excellent electrical insulation and durability, while the bronze contacts plated with 0.38 μm gold ensure superior conductivity and corrosion resistance.
Rated for 12 amperes current and 350 volts operating voltage, the socket maintains functional integrity over a temperature range from -55°C to 125°C, making it suitable for industrial, manufacturing, laboratory, and commercial electronic equipment. The right angle orientation assists in PCB layout optimization, and the solder termination type facilitates secure mounting on printed circuit boards using through-hole technology.
This socket mates with 0.64 mm square pin headers, including the Molex 90120 series, in both straight and 90° configurations, ensuring wide compatibility. Its signal board-to-board connector system design makes it ideal for various electronic components requiring stable and precise interconnections.
Overall, the Molex 90148-1204 PCB socket is an essential component for electrical and electronic assemblies where performance and reliability are critical. It is widely used across electronics manufacturing, industrial automation, communications equipment, and related fields.
Features 4 contacts arranged in a single row with a 2.54 mm pitch. Constructed with polyester housing and bronze female contacts for durability. Rated for 12 amperes current and 350 volts voltage operation. Gold-plated contacts ensure reliable signal connections and corrosion resistance.
Designed for solder termination with right angle orientation for PCB mounting. Operates reliably within temperature range -55°C to 125°C. Compatible with 0.64 mm square pin headers including Molex 90120 series. Ideal for board-to-board signal connector system in electronic devices.
Explore more electronic components and connectors with EnvMart for your industrial, laboratory, manufacturing, and commercial electronic needs.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket is rated for a current of 12 amperes and an operating voltage of 350 volts.
It features a pitch of 2.54 mm and has 4 contacts arranged in a single row.
The housing is made from polyester, and the contacts are bronze with gold plating for enhanced conductivity and corrosion resistance.
It operates reliably within a temperature range of -55°C to 125°C.
This model is designed for solder termination, allowing secure mounting on printed circuit boards using through-hole technology.
It is compatible with 0.64 mm square pin headers, including the Molex 90120 series.
This socket features a right angle orientation, which assists in optimizing PCB layout.
This model has a single row configuration for its contacts.
It is designed as a signal board-to-board connector system, suitable for various electronic components.
The country of origin for this PCB socket is India.
This socket has female contacts.
The gold plating on the contacts ensures reliable signal connections and provides corrosion resistance.
