DiodesZetex Type P-Channel Enhancement MOSFET, 3A, 60V, 6-Pin SOT-23 Package ZXMP6A17E6TA
Specifications
| Country of Origin | India |
|---|---|
| Brand | DiodesZetex |
| Height | 1.3mm |
| Length | 3.1mm |
| Model | ZXMP6A17E6TA |
| Width | 1.8mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 6 |
| Automotive Standard | AEC-Q101 |
| Channel Type | Type P |
| Maximum Continuous Drain Current Id | 3A |
| Maximum Drain Source Voltage Vds | 60V |
| Maximum Drain Source Resistance Rds | 125mΩ |
| Channel Mode | Enhancement |
| Maximum Power Dissipation Pd | 1.7W |
| Typical Gate Charge Qg @ Vgs | 17.7nC |
| Maximum Gate Source Voltage Vgs | -20, +20V |
| Forward Voltage Vf | -0.95V |
Key Features
- Maximum continuous drain current of 3 amperes for robust operation.
- Drain-source voltage rating of 60 volts for medium voltage applications.
- Compact SOT-23 6-pin surface mount package enables easy PCB integration.
- Low maximum drain-source resistance of 125 milliohms enhances efficiency.
- Operating temperature range from -55°C to 150°C ensures reliability in harsh environments.
- Typical gate charge of 17.7 nanocoulombs at specified gate voltage for efficient switching.
- Maximum power dissipation of 1.7 watts for thermal management.
- Automotive standard compliant with AEC-Q101 for quality and durability.
Product Description
DiodesZetex ZXMP6A17E6TA is a high-performance P-Channel Enhancement MOSFET designed for electronic and power semiconductor applications. Featuring a maximum continuous drain current of 3 amperes and a drain-source voltage up to 60 volts, this device supports efficient switching and amplification in circuits requiring reliable power control.
The MOSFET is packaged in a compact 6-pin SOT-23 surface mount configuration, facilitating easy incorporation into modern electronic designs. It offers a low maximum drain-source resistance of 125 milliohms, minimizing power loss and heat generation, thus enhancing overall circuit efficiency.
This device operates reliably in a broad temperature range from -55°C to 150°C, making it suitable for demanding industrial, automotive, and commercial environments. The typical gate charge of 17.7 nanocoulombs at specified gate voltage supports fast switching speeds with minimal energy loss.
With a maximum power dissipation of 1.7 watts and compliance to the automotive AEC-Q101 standard, the ZXMP6A17E6TA MOSFET ensures durability for automotive and industrial applications. Its small dimensions (length 3.1mm, width 1.8mm, height 1.3mm) enable high-density circuit layouts while maintaining performance.
Applications include DC-DC converters, power management circuits, automotive electronics, and general purpose switching in power semiconductor devices. This component meets the requirements for surface mount assembly, providing reliable operation in various electronic devices.
Maximum continuous drain current of 3 amperes for robust operation. Drain-source voltage rating of 60 volts for medium voltage applications. Compact SOT-23 6-pin surface mount package enables easy PCB integration. Low maximum drain-source resistance of 125 milliohms enhances efficiency.
Operating temperature range from -55°C to 150°C ensures reliability in harsh environments. Typical gate charge of 17.7 nanocoulombs at specified gate voltage for efficient switching. Maximum power dissipation of 1.7 watts for thermal management.
Automotive standard compliant with AEC-Q101 for quality and durability. Explore further semiconductors and MOSFETs in the Discrete Semiconductor category at EnvMart for your industrial, automotive, and electronic component projects.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The ZXMP6A17E6TA has a maximum continuous drain current of 3 amperes, allowing for robust operation in various applications.
This MOSFET has a drain-source voltage rating of 60 volts, suitable for medium voltage applications.
The device is packaged in a compact SOT-23 configuration and features 6 pins, facilitating easy surface mount integration.
The maximum drain-source resistance for the ZXMP6A17E6TA is 125 milliohms, which enhances efficiency by minimizing power loss.
It operates reliably within a temperature range of -55°C to 150°C, making it suitable for harsh environments.
The typical gate charge at the specified gate voltage is 17.7 nanocoulombs, supporting efficient switching.
The maximum power dissipation for the ZXMP6A17E6TA is 1.7 watts, which aids in thermal management.
Yes, it is compliant with the automotive standard AEC-Q101, ensuring quality and durability for automotive applications.
The dimensions of the ZXMP6A17E6TA are 3.1mm in length, 1.8mm in width, and 1.3mm in height.
This model features a P-Channel enhancement type, which is suitable for various electronic applications.
The maximum gate-source voltage for the ZXMP6A17E6TA is -20V to +20V, allowing for versatile control in circuits.
It is suitable for applications such as DC-DC converters, power management circuits, and automotive electronics.
