| Country of Origin | China |
|---|---|
| Brand | onsemi |
| Height | 1.01mm |
| Length | 3.04mm |
| Model | MMBD914LT1G |
| Width | 1.4mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Sub Type | Switching Diode |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Single |
| Peak Non-Repetitive Forward Surge Current Ifsm | 2A |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 4ns |
| Maximum Forward Current If | 200mA |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 100V |
| onsemi Switching Diode, Single, 200 mA, 3-Pin 100 V SOT-23 MMBD914LT1GBrand | onsemi |
onsemi MMBD914LT1G switching diode is a single diode designed for high speed switching applications. This surface mount diode in a SOT-23 package is ideal for automated insertion in modern electronic assemblies.
The diode can support a maximum forward current of 200mA and withstands a maximum peak repetitive reverse voltage of 100V, making it suitable for various switching tasks.
Operating temperature ranges from -55°C up to 150°C, enabling reliability in diverse environmental conditions. Peak non-repetitive forward surge current is rated at 2A, providing endurance during transient events.
With a maximum power dissipation of 300mW and a peak reverse recovery time of 4 nanoseconds, this diode offers efficient power handling and rapid switching capabilities required in telecommunications, automotive electronics, and industrial control circuits.
The compact dimensions of 3.04mm length, 1.4mm width, and 1.01mm height enable use in space-constrained applications. This diode conforms to the AEC-Q101 automotive standard, ensuring robust performance in automotive electronics environments.
Supports maximum forward current of 200mA. Compact SOT-23 package with 3 pins for surface mounting. Maximum peak repetitive reverse voltage of 100V. Operating temperature range from -55°C to 150°C. Peak non-repetitive forward surge current of 2A.
Maximum power dissipation of 300mW. Peak reverse recovery time of 4ns for fast switching. Meets AEC-Q101 automotive standard. Compact size: 3.04mm x 1.4mm x 1.01mm. Ideal for high speed switching applications in electronic circuits.
This switching diode is used extensively in industrial, automotive, and electronic manufacturing sectors for effective signal and power switching tasks. Explore a wide range of semiconductors and discrete components at EnvMart for your engineering and production needs.
