onsemi Single Type P-Channel JFET-Channel JFET, 15 V, -2 to -25 mA, 3-Pin SOT-23 MMBFJ176

Free Delivery in India | Lowest Global Shipping Charges

onsemi Single Type P-Channel JFET-Channel JFET, 15 V, -2 to -25 mA, 3-Pin SOT-23 MMBFJ176

Name: onsemi Single Type P-Channel JFET-Channel JFET, 15 V, -2 to -25 mA, 3-Pin SOT-23 MMBFJ176
Brand: onsemi
SKU: 410125
Price: 0.27 USD
Availability: InStock



Category Discrete Semiconductor Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	0.93mm
Length	2.92mm
Model	MMBFJ176
Width	1.3mm
Mount Type	Surface
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	SOT-23
Sub Type	JFET
Minimum Operating Temperature	-55°C
Pin Count	3
Channel Type	Type P
Maximum Drain Source Voltage Vds	15V
Maximum Drain Source Resistance Rds	250Ω
Maximum Power Dissipation Pd	225mW
Maximum Gate Source Voltage Vgs	30V
Drain Source Current Ids	-2 to -25 mA

Key Features

This JFET features a single-channel, P-type configuration for efficient switching.
It supports drain source current ranging from -2 to -25 mA.
The device is housed in a compact 3-pin SOT-23 surface mount package suitable for space-saving PCB designs.
It has a maximum power dissipation rating of 225 mW, ensuring reliable operation.
Operating temperature ranges from -55°C to a maximum of 150°C, suitable for diverse environments.
Maximum gate source voltage of 30 V provides robust control characteristics.
Physical dimensions include 2.92 mm length, 1.3 mm width, and 0.93 mm height.
The device has a maximum drain source resistance of 250 Ω, optimizing conduction properties.

Product Description

onsemi MMBFJ176 Single Type P-Channel JFET-Channel JFET is a high-quality discrete semiconductor device designed for use in electronic components requiring efficient switching and signal amplification. It is optimized for surface mount applications with a SOT-23 package, providing compactness and ease of assembly.

Featuring a P-channel configuration, this JFET supports a maximum drain source voltage of 15 V and a drain source current range of -2 to -25 mA, making it suitable for precise analog and digital switching applications. The device's maximum power dissipation of 225 mW allows reliable performance under continuous operation.

Designed to withstand operating temperatures from -55°C to 150°C, the MMBFJ176 is robust for industrial, laboratory, and commercial electronics applications. Its maximum gate source voltage of 30 V ensures stable control within circuits.

With a compact footprint of 2.92 mm length, 1.3 mm width, and 0.93 mm height, the 3-pin SOT-23 package supports efficient PCB layout and mass production. The maximum drain source resistance of 250 Ω provides good conduction characteristics while minimizing losses.

This product is ideal for use in electronic devices, signal processing equipment, and control systems across industrial, laboratory, and manufacturing sectors. The surface mount compatibility supports automated assembly and improved production efficiency.

It does not comply with automotive standards and is designed as a standard high-electron mobility transistor suitable for various Discrete Semiconductor applications. Explore more from the semiconductor category on EnvMart for diverse and reliable components tailored to your electronics design needs.
