DiodesZetex Dual NPN + PNP Transistor 30 V, 1.5 A, 1.7 W Power Dissipation, 6-Pin SOT-23 Package ZXTC2045E6TA

DiodesZetex ZXTC2045E6TA is a dual NPN + PNP bipolar transistor designed for surface mount applications. Rated at a maximum collector current of 1.5 A and collector-emitter voltage of 30 V, this transistor delivers efficient switching and amplification capabilities in compact electronic circuits.

Featuring a low-profile 6-pin SOT-23 package measuring 3.1 mm in length, 3.0 mm in width, and 0.8 mm in height, the device integrates both NPN and PNP transistor polarities, simplifying circuit design and reducing component count.

This transistor offers a maximum power dissipation of 1.7 W and operates reliably between -55°C and 150°C, meeting AEC-Q101 automotive standard requirements. Its maximum transition frequency of 265 MHz ensures suitability for high-frequency signal processing and amplification tasks.

The ZXTC2045E6TA's isolated transistor configuration and high minimum DC current gain of 180 make it ideal for various industrial and electronic applications including automotive electronics, power management, signal amplification, and switching functions in commercial and industrial electronic devices.

Supplied in compact 6-pin SOT-23 package for surface mounting. Dual NPN + PNP transistor polarities integrated in one device. Maximum collector current of 1.5 A and voltage rating of 30 V. Power dissipation of 1.7 W supports robust operation.

Wide operating temperature range from -55°C to 150°C. Automotive standard AEC-Q101 compliant ensuring high reliability. Maximum transition frequency of 265 MHz for high-speed applications. Dimensions suitable for compact electronic designs.

This transistor is suited for industrial, automotive, electronics manufacturing, and power management applications. Explore EnvMart's extensive range of Bipolar Transistors and semiconductor devices for reliable circuit solutions.
