DiodesZetex General Purpose NPN Bipolar Transistor 5A 25V 2.5W SOT-223 FZT1049ATA

DiodesZetex FZT1049ATA is a high-performance NPN bipolar transistor designed for general purpose electronic applications. It offers a maximum DC collector current of 5 amperes and can handle collector-emitter voltages up to 25 volts, making it suitable for various switching and amplification circuits.

The device is housed in a compact 4-pin SOT-223 surface mount package, facilitating easy PCB integration in space-constrained designs. Its minimum DC current gain of 40 ensures sufficient amplification, while the maximum power dissipation rating of 2.5 watts guarantees stability and reliability under typical operating conditions.

This transistor supports operating temperatures from -55°C to 150°C, accommodating demanding thermal environments. Its maximum transition frequency of 180 MHz enables high-speed switching applications, valuable in industrial, automotive, and consumer electronics sectors.

Compliant with automotive standard AEC-Q101, FZT1049ATA is verified for use in automotive systems requiring rigorous quality assurance. The precise physical dimensions - 6.55 mm length, 7.1 mm width, and 1.8 mm height - support accurate PCB layout design.

Typical applications include power management, amplification stages in audio devices, and switching tasks in industrial control circuits. Its single transistor configuration and NPN polarity make it versatile for various electronic designs.

The transistor supports a maximum DC collector current of 5 amperes. Maximum collector-emitter voltage rating of 25 volts ensures reliable operation. Power dissipation capability of 2.5 watts maintains stable thermal performance.

4-pin SOT-223 surface mount package offers compact design advantages. Minimum DC current gain of 40 provides efficient signal amplification. Operating temperature range from -55°C to 150°C suits industrial environments. Maximum transition frequency of 180 MHz enables fast switching applications.

Automotive standard AEC-Q101 compliance ensures high reliability in automotive use cases. Physical dimensions support precise PCB integration. Explore the extensive range of Bipolar Transistors and semiconductor components available on EnvMart for your industrial and electronic design needs.
