Taiwan Semiconductor 60 V 2 A Schottky Diode Surface Mount DO-214AA Package SS26 R4

Taiwan Semiconductor SS26 R4 is a high-performance 2 A Schottky diode designed for surface mount applications in electronic circuits requiring low forward voltage drop and high efficiency.

This Schottky diode supports a maximum continuous forward current of 2 A and a peak reverse repetitive voltage of 60 V, providing reliable operation in demanding power management tasks.

The DO-214AA package ensures easy and compact PCB assembly while sustaining operation over a wide temperature range from -65°C to 150°C, making it suitable for industrial, automotive, and consumer electronics.

Its low forward voltage drop of 0.7 V reduces power losses and improves overall energy efficiency within circuits. The diode configuration is single with a 2-pin layout, optimized for quick integration and high current capacity.

This Schottky diode supports a maximum continuous forward current of 2 A. Peak reverse repetitive voltage rating is 60 V. Compact DO-214AA surface mount package. Maximum forward voltage drop at 0.7 V for low power loss. Operating temperature range from -65°C to 150°C.

Peak non-repetitive forward surge current rating of 50 A. Physical dimensions: length 4.75 mm, width 3.73 mm, height 2.41 mm. Single diode with 2-pin configuration. Common applications include industrial electronics, power supply circuits, automotive electronics, and other high-efficiency power rectification needs.
