Taiwan Semiconductor 600 V 1 A Fast Recovery Surface Mount Switching Rectifier DO-214AC RS1J R2

Taiwan Semiconductor RS1J R2 is a 600 V, 1 A fast recovery switching rectifier designed for surface mount applications. It uses a compact DO-214AC (SMA) package, making it ideal for space-constrained electronic devices and circuits. The rectifier is engineered to handle maximum continuous forward current of 1 A with a peak reverse repetitive voltage of 600 V, ensuring robust performance in power regulation and switching applications.

Operating temperature ranges from -55°C to 150°C, enabling use in diverse industrial and electronic environments. The device offers a peak reverse recovery time of 250 ns and a maximum forward voltage drop of 1.3 V, minimizing power dissipation and improving efficiency in switching circuits.

This single diode rectifier with 2 pins supports a peak non-repetitive forward surge current of 30 A, thus providing resilience against transient electrical events. Its physical dimensions (4.6 mm length, 2.83 mm width, 2.3 mm height) support compact PCB layouts while maintaining reliable electrical performance.

Compliance with Underwriters Laboratory Classification 94V-O standard ensures high safety and quality standards suitable for industrial and commercial electronics manufacturing. Taiwan Semiconductor’s RS1J R2 rectifier is well-suited for power conversion, voltage regulation, and high-speed switching applications commonly found in electronics, industrial controls, and HVAC systems.

Key Features:. 1 A maximum continuous forward current supports standard circuit demands. 600 V peak reverse repetitive voltage ensures robustness against voltage spikes. Fast 250 ns reverse recovery time optimizes switching efficiency.

DO-214AC surface mount package suits modern PCB assembly. Wide temperature operating range of -55°C to 150°C enhances durability. Low forward voltage drop of 1.3 V reduces energy losses. Single diode configuration with 2-pin design for simplified installation.

High surge current tolerance at 30 A safeguards against transient surges. Compact dimensions enable use in dense electronic assemblies. Certified to Underwriters Laboratory 94V-O standard for safety compliance.

This product is ideal for industrial, electronic manufacturing, laboratory, and HVAC sectors needing reliable rectification solutions in surface mount layouts. Explore similar semiconductor components in the EnvMart catalog for diverse application needs.
