Vishay Bridge Rectifier 100 V 250 A, 4-Pin Through Hole KBU6B-E4/51

Free Delivery in India | Lowest Global Shipping Charges

Vishay Bridge Rectifier 100 V 250 A, 4-Pin Through Hole KBU6B-E4/51

Name: Vishay Bridge Rectifier 100 V 250 A, 4-Pin Through Hole KBU6B-E4/51
Brand: Vishay
SKU: 200959
Price: 4.1 USD
Availability: InStock



Category Bridge Rectifier Brand Vishay Condition New

Specifications

Country of Origin	India
Brand	Vishay
Height	19.3mm
Length	23.7mm
Model	KBU6B-E4/51
Width	7.1mm
Mount Type	Through Hole
Series	KBU6
Configuration	Single
Maximum Operating Temperature	150°C
Package Type	KBU
Minimum Operating Temperature	-50°C
Number of Phases	1
Pin Count	4
Peak Reverse Repetitive Voltage Vrrm	100V
Peak Reverse Current Ir	5μA
Peak Non-Repetitive Forward Surge Current Ifsm	250A
Forward Current If	6A
Peak Forward Voltage Vf	1V
Vishay Bridge Rectifier, 6A, 100V, 4-PinBrand	Vishay
Vishay Bridge Rectifier, 200 V 250 A, 4-Pin SingleBrand	Vishay

Key Features

This bridge rectifier features a 4-pin single configuration suitable for full-wave rectification.
It supports a maximum forward current of 6 A for reliable operation.
The device is rated for a peak non-repetitive forward surge current of 250 A.
Operating temperature ranges from -50°C to 150°C for versatile applications.
Compact dimension with length 23.7 mm, width 7.1 mm, and height 19.3 mm.
The package type is KBU, designed for through-hole mounting on PCBs.
It delivers a peak forward voltage drop of approximately 1 V ensuring efficiency.
Low peak reverse leakage current of 5 μA increases performance stability.

Product Description

Vishay KBU6B-E4/51 Bridge Rectifier is a 4-pin single-phase device designed for converting AC input into DC output through full-wave rectification. Supporting a peak reverse voltage of 100 V and a forward current of 6 A, it is ideal for electronic assemblies requiring reliable rectification in a compact through-hole KBU package.

Featuring high surge current capability with a peak non-repetitive forward surge current of 250 A, this rectifier ensures durability under transient loads. It operates efficiently within a temperature range of -50°C to 150°C, making it suitable for industrial, consumer electronics, and power supply applications.

The device package includes soldering pins for printed circuit board mounting, designed to fit compactly while providing thermal efficiency. Its low forward voltage drop (~1 V) facilitates energy-efficient conversion, and minimal leakage current enhances overall device stability.

Physical dimensions of 23.7 mm length, 7.1 mm width, and 19.3 mm height enable integration in tight circuitry layouts. The isolating voltage rating of 1500 Vrms and single phase configuration add to its versatility for diverse semiconductor applications.

This rectifier is applicable in power supplies, industrial equipment, and electronic control systems. It can withstand high surge currents and temperature extremes common in demanding environments. Suitable for laboratory, HVAC, manufacturing, and automotive electronics uses.

The design follows Vishay Semiconductor's standards for reliability and performance. KBU series bridge rectifiers provide robust, compact solutions for discrete semiconductor needs. Explore more Vishay Semiconductor products and Bridge Rectifier options available on EnvMart for various industrial and electronic applications.
