Vishay 800 V 1 A General Purpose Standard Recovery Diode, Surface Mount, DO-214BA Package GF1K-E3/67A
Specifications
| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Height | 2.74mm |
| Length | 4.75mm |
| Model | GF1K-E3/67A |
| Width | 2.9mm |
| Mount Type | Surface |
| Series | GF1K |
| Maximum Operating Temperature | 175°C |
| Package Type | DO-214BA |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 800V |
| Diode Configuration | Single |
| Rectifier Type | General Purpose |
| Peak Reverse Current Ir | 5μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 30A |
| Maximum Forward Voltage Vf | 1.2V |
| Peak Reverse Recovery Time trr | 2μs |
Key Features
- Supports a maximum continuous forward current of 1 A.
- Maximum reverse repetitive voltage rating is 800 V.
- Surface mount package type is DO-214BA for compact PCB integration.
- Peak non-repetitive forward surge current rating of 30 A ensures high transient tolerance.
- Maximum forward voltage drop is 1.2 V for low conduction losses.
- Operates reliably from -65°C up to a maximum temperature of 175°C.
- Peak reverse recovery time of 2 microseconds supports fast switching applications.
- Complies with RoHS environmental standards and automotive standard AEC-Q101.
Product Description
Vishay GF1K-E3/67A is a high-efficiency, standard recovery power diode designed for general-purpose rectification and switching applications in industrial and electronic circuits. It features a surface mount DO-214BA package suitable for space-constrained PCB layouts and offers robust performance with a maximum continuous forward current of 1 ampere and a peak repetitive reverse voltage of 800 volts.
This single diode configuration ensures easy integration into power supply circuits, with a low forward voltage drop of 1.2 volts to minimize conduction losses and improve energy efficiency. Its peak non-repetitive forward surge current of 30 amperes enables reliable handling of transient current surges, protecting sensitive components downstream.
The GF1K-E3/67A diode operates effectively over a wide temperature range from -65°C to 175°C, making it suitable for harsh industrial and automotive environments where thermal stability is critical. The quick peak reverse recovery time of 2 microseconds ensures enhanced switching speed for improved performance in high-frequency circuits and power conversion applications.
Manufactured in compliance with RoHS environmental directives and meeting the automotive-grade AEC-Q101 standard, this diode provides a reliable and safe solution for diverse applications including power supplies, motor drives, and automotive electronics.
Physical dimensions are compact with a length of 4.75 mm, width of 2.9 mm, and height of 2.74 mm, facilitating efficient PCB design and assembly in automated manufacturing environments.
Maximum continuous forward current: 1 A. Peak reverse repetitive voltage: 800 V. Package: Surface mount DO-214BA. Peak non-repetitive surge current: 30 A. Forward voltage drop: 1.2 V maximum. Operating temperature range: -65°C to 175°C.
Peak reverse recovery time: 2 μs. Complies with RoHS and AEC-Q101 automotive standards. Dimensions (L x W x H): 4.75 mm x 2.9 mm x 2.74 mm. Single diode with 2 pins.
This diode is ideal for use in industrial, automotive, electronic manufacturing, and power management applications requiring reliable general-purpose rectification and switching solutions.
Explore more semiconductor components and power diodes in the EnvMart catalog for your electronic and industrial design needs.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay GF1K-E3/67A is 1 A.
This model has a peak reverse repetitive voltage rating of 800 V.
It comes in a surface mount DO-214BA package, which is suitable for compact PCB integration.
The peak non-repetitive forward surge current rating is 30 A, allowing it to handle transient current surges effectively.
The maximum forward voltage drop is 1.2 V, which helps in minimizing conduction losses.
It operates reliably within a temperature range of -65°C to 175°C.
The peak reverse recovery time is 2 microseconds, which supports fast switching applications.
The dimensions are 4.75 mm in length, 2.9 mm in width, and 2.74 mm in height.
It complies with the automotive standard AEC-Q101, ensuring it meets specific performance criteria for automotive applications.
Yes, the Vishay GF1K-E3/67A complies with RoHS environmental standards.
This diode has a pin count of 2, making it simple to integrate into circuits.
It is classified as a general-purpose rectifier, suitable for various rectification and switching applications.
