onsemi 1.33 V Zener Diode Single 500 mW 5% Voltage Regulator Surface Mount 2-Pin SOD-123 MMSZ3V3T1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi 1.33 V Zener Diode Single 500 mW 5% Voltage Regulator Surface Mount 2-Pin SOD-123 MMSZ3V3T1G

Name: onsemi 1.33 V Zener Diode Single 500 mW 5% Voltage Regulator Surface Mount 2-Pin SOD-123 MMSZ3V3T1G
Brand: onsemi
SKU: 200491
Price: 0.03 USD
Availability: InStock



Category Zener Diodes Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.35mm
Length	3.68mm
Model	MMSZ3V3T1G
Mount Type	Surface
Series	MMSZxxxT1G
Maximum Operating Temperature	150°C
Package Type	SOD-123
Minimum Operating Temperature	-55°C
Standards/Approvals	RoHS
Pin Count	2
Number of Elements per Chip	1
Maximum Power Dissipation Pd	500mW
Diode Configuration	Single
Test Current It	5mA
Maximum Reverse Leakage Current	5μA
Nominal Zener Voltage Vz	3.3V
Zener Type	Voltage Regulator
Maximum Zener Impedance	95Ω
Surface Mount case	SOD-123

Key Features

This diode features a nominal Zener voltage of 3.3 V and a test current of 5 mA.
Maximum power dissipation is rated at 500 mW, supporting reliable voltage regulation.
It is designed for surface mount applications with a compact SOD-123 package.
The device features a maximum Zener impedance of 95 Ω and a maximum reverse leakage current of 5 μA.
Temperature operating range spans from -55°C to 150°C for versatile industrial use.
Pin count is 2, ensuring simple integration into circuits.
Complies with RoHS standards, ensuring environmental compliance.
This diode belongs to the MMSZxxxT1G series by onsemi, specially designed for voltage regulation.

Product Description

onsemi MMSZ3V3T1G is a single element Zener diode designed as a voltage regulator with a nominal Zener voltage of 3.3 V. It supports a maximum power dissipation of 500 mW and maintains stability with a 5% voltage tolerance.

This surface mount device comes in a low-profile 2-pin SOD-123 package measuring 3.68 mm in length and 1.35 mm in height, making it suitable for compact PCB assemblies. Featuring a test current of 5 mA and maximum Zener impedance of 95 Ω, it provides precise voltage regulation and protection in electronic circuits.

The diode operates reliably over a wide temperature range from -55°C to 150°C, suitable for industrial, commercial, and semiconductor applications requiring robustness. Its maximum reverse leakage current of 5 μA ensures minimal leakage losses, contributing to energy-efficient circuit design.

onsemi's MMSZxxxT1G series is widely used in semiconductor industries, including power regulation and circuit protection in industrial and electronic systems. Nominal Zener voltage of 3.3 V ensures stable voltage regulation.

Surface mount SOD-123 package facilitates automated PCB assembly. Wide temperature range from -55°C to 150°C supports diverse operating environments. Compliant with RoHS environmental standards. Reliable maximum power dissipation of 500 mW for effective voltage regulation.

Compact size allows integration into space-limited designs. Low reverse leakage current minimizes energy loss. Designed for industrial, commercial electronics, and power supply applications. Explore a wide range of semiconductor components, including Zener Diodes from onsemi at EnvMart for your industrial and electronic project needs.
