onsemi PNP Transistor 3-Pin SOT-23, 200 mA Collector Current, 40 V Collector-Emitter Voltage, 300 mW Power MMBT3906LT1G

Free Delivery in India | Lowest Global Shipping Charges

onsemi PNP Transistor 3-Pin SOT-23, 200 mA Collector Current, 40 V Collector-Emitter Voltage, 300 mW Power MMBT3906LT1G

Name: onsemi PNP Transistor 3-Pin SOT-23, 200 mA Collector Current, 40 V Collector-Emitter Voltage, 300 mW Power MMBT3906LT1G
Brand: onsemi
SKU: 196935
Price: 0.06 USD
Availability: InStock



Category Bipolar Transistors Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	1.11mm
Length	3.04mm
Model	MMBT3906LT1G
Width	1.4mm
Mount Type	Surface
Series	MMBT3906L
Maximum Operating Temperature	150°C
Package Type	SOT-23
Pin Count	3
Maximum Collector Emitter Voltage Vceo	-40V
Minimum DC Current Gain hFE	30
Transistor Polarity	PNP
Maximum Emitter Base Voltage VEBO	5V
Maximum Collector Base Voltage VCBO	40V
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	300mW
Maximum DC Collector Current Idc	-200mA
Transistor Configuration	Single
Maximum Transition Frequency ft	250MHz
PNP transistor,MMBT3906 0.2ABrand	ON Semiconductor

Key Features

Compact SOT-23 surface mount package suitable for space-limited designs.
Maximum power dissipation of 300 mW for efficient circuit operation.
Minimum DC current gain (hFE) of 30 ensures reliable amplification.
Maximum transition frequency of 250 MHz supports high-frequency applications.
Automotive qualified to AEC-Q101 standard ensuring high reliability.
Operating temperature up to 150°C suitable for demanding environments.
Designed for general-purpose PNP transistor applications in electronic circuits.
3-pin layout enables easy integration in surface-mount PCB designs.

Product Description

onsemi MMBT3906LT1G is a general-purpose PNP bipolar junction transistor in a compact 3-pin SOT-23 surface-mount package. It supports a maximum DC collector current of 200 mA and a maximum collector-emitter voltage of 40 V, making it suitable for low power switching and amplification tasks in electronic circuits.

The transistor features a maximum power dissipation of 300 mW, enabling efficient operation without excessive heat generation in typical applications. It has a minimum DC current gain (hFE) of 30 and a maximum transition frequency of 250 MHz, allowing it to handle moderate frequency signals effectively.

This device meets the automotive AEC-Q101 qualification standard, providing enhanced robustness and reliability for automotive and industrial electronics. Its operating temperature extends up to 150°C, making it viable for use in harsh or elevated temperature environments.

The SOT-23 package has dimensions of approximately 3.04 mm length, 1.4 mm width, and 1.11 mm height, offering compactness for dense PCB layouts.

Applications include general-purpose amplification, switching, and signal processing tasks in consumer electronics, industrial controls, automotive electronics, and communication devices.

Compact SOT-23 surface mount package for space-saving designs. Reliable PNP transistor with 200 mA collector current capacity. Suitable for general amplification and switching roles. Automotive qualified to AEC-Q101 standard.

Operates reliably up to 150°C ambient temperature. High transition frequency for effective signal handling. Low power dissipation maintaining thermal efficiency. Easy surface-mount integration on PCBs.

Choose onsemi MMBT3906LT1G for dependable bipolar transistor performance in industrial, automotive, and electronics manufacturing applications. Browse further semiconductor components and transistors on EnvMart for complementary parts and full project solutions.
