Vishay Schottky Diode 30 V 1 A 2-Pin Surface Mount DO-214AA VS-10BQ030-M3/5BT
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 4.57mm |
| Brand | Vishay |
| Height | 3.94mm |
| Length | 4.7mm |
| Model | VS-10BQ030-M3/5BT |
| Width | 3.8mm |
| Mount Type | Surface |
| Series | VSX |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 500μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 430A |
| Maximum Forward Voltage Vf | 440mV |
| Schottky barrier diode,10BQ030 1A 30VBrand | Vishay |
| Vishay 30V 1A, Schottky Diode, 2-Pin DO-214AA VS-10BQ030PBFBrand | Vishay |
Key Features
- The diode is packaged in a 2-pin DO-214AA case suitable for surface mount PCB assembly.
- It supports a maximum continuous forward current of 1 ampere with a peak reverse voltage of 30 volts.
- This Schottky rectifier features a low maximum forward voltage of 440 mV and a fast switching performance.
- It operates reliably in temperatures from -55°C to 150°C.
- The diode exhibits very short reverse recovery times suitable for high efficiency power applications.
- Peak non-repetitive forward surge current rating is 430 A, supporting transient overload conditions.
- The pin count is 2, arranged in a single diode configuration.
- This semiconductor is ideal for industrial, electronic power supply, and fast switching applications.
Product Description
Vishay VS-10BQ030-M3/5BT Schottky Diode 30 V 1 A in a 2-pin DO-214AA surface mount package is designed for efficient power rectification with very low forward voltage drop and fast switching action.
This Schottky rectifier operates with a maximum continuous forward current of 1 A and a peak reverse repetitive voltage of 30 V, making it suitable for power supplies, switching power circuits, and electronic devices requiring energy-efficient diode operation.
The diode supports a wide temperature range from -55°C minimum operating temperature to a maximum operating temperature of 150°C, ensuring reliability in harsh industrial and commercial environments.
The low maximum forward voltage of 440 mV reduces conduction losses and enhances overall circuit efficiency.
Its extremely short reverse recovery time suits applications that demand fast switching and energy conservation, including industrial control systems, power management circuits, and renewable energy electronics.
The robust surge current capability of 430 A peak non-repetitive forward surge current protects the device against transient overloads common in industrial and automotive power circuits.
The compact DO-214AA package with dimensions approximately 4.7 mm length, 3.8 mm width, 3.94 mm height, and 4.57 mm diameter pins facilitates easy integration into compact PCB designs.
The diode is a high-performance Schottky rectifier suitable for electronic component applications. It finds use in laboratory, manufacturing, power electronics, and general industrial automated systems. Surface mount design supports efficient automated assembly processes.
Set your design apart with this reliable Vishay Schottky diode as a key component in power electronics projects. Explore the extensive collection of semiconductor components and Schottky diodes at EnvMart for enhanced engineering solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 1 ampere.
This diode has a peak reverse repetitive voltage rating of 30 volts.
The dimensions of the DO-214AA package are approximately 4.7 mm in length, 3.8 mm in width, and 3.94 mm in height, with pin diameter of 4.57 mm.
It operates reliably within a temperature range from -55°C to 150°C.
The maximum forward voltage drop is 440 mV.
The peak non-repetitive forward surge current rating is 430 A.
This model supports surface mount PCB assembly.
It features a single diode configuration with a pin count of 2.
The peak reverse current is rated at 500 μA.
This diode is suitable for power supplies, switching power circuits, and electronic devices requiring efficient diode operation.
This model belongs to the VSX series of Schottky diodes.
The country of origin for this diode is India.
