Molex Mini-Fit Jr Series Right Angle Through Hole PCB Header 16 Contact 4.2 mm Pitch 2 Row Shrouded 39-30-1160

Molex 39-30-1160 Mini-Fit Jr Series Right Angle Through Hole PCB Header is designed for high-density, high current wire-to-board applications. With 16 contacts arranged in two rows at a 4.2 mm pitch, this shrouded header offers reliable connections in various industrial and electronic systems.

The housing is made from durable nylon that meets UL94V-0 or UL94V-2 standards, providing insulation and safety. The brass contact material with tin plating assures excellent conductivity and corrosion resistance. Its fully isolated terminals prevent contact damage from debris and arcing, enhancing longevity.

This PCB header features a right angle orientation suitable for compact board designs and is fixed by through hole mounting with a 3.6 mm tail pin length to ensure mechanical stability. Operating voltage rating is 600V and the connector can safely handle up to 13A current per circuit.

The design includes scoop-proof housings that shield contact pins during mating, plus polarization and keying features that prevent misalignment and incorrect connections. A positive locking mechanism with an audible click confirms secure mating, essential for shock and vibration resistance in industrial environments.

Applications for this Mini-Fit Junior connector include consumer white goods, office equipment, industrial automation, networking devices, and rack-mount servers. The product is manufactured in Mexico and operates reliably within a temperature range from -40°C to 105°C.

Supports up to 13A current per circuit suitable for high current applications. Manufactured with nylon housing material ensuring durable insulation. Features fully isolated terminals protecting against debris and arcing.

Right angle orientation with solder termination and male contact gender. Includes scoop-proof housings to prevent pin terminal damage during mating. Equipped with polarization and keying to avoid mismating of connectors.

Positive locking mechanism ensures secure connection and audible click confirms mating. Operates between -40°C and 105°C temperature range. Through hole mount type with 3.6 mm tail pin length for stable PCB fixation. Explore more high-quality PCB Headers and connectors in the Electronics & Electricals category at EnvMart for your industrial and manufacturing needs.
