DiodesZetex Small Signal NPN Transistor 600 mA 40 V 3-Pin SOT-23 MMBT2222A-7-F

DiodesZetex MMBT2222A-7-F is a reliable small signal NPN bipolar junction transistor designed for discrete semiconductor applications. It supports a maximum collector current of 600 mA and a collector-emitter voltage up to 40 V, making it suitable for switching and amplification tasks in various electronic circuits.

The transistor is housed in a compact surface-mount SOT-23 package with three pins, facilitating easy integration into compact PCB designs. Its thermal characteristics allow it to operate safely between -55°C and 150°C, meeting automotive AEC-Q101 standards for harsh environment applications.

Key electrical parameters include a collector base voltage of 75 V, a power dissipation capability of 300 mW, and a minimum gain (hFE) of 35, ensuring stable operation in signal processing tasks.

This device is applicable in diverse sectors such as industrial control, automotive electronics, consumer devices, and laboratory instrumentation, where small signal transistors are required for amplification and switching.

This transistor features a maximum collector base voltage of 75 V. It has a maximum power dissipation rating of 300 mW. The device offers a minimum DC current gain of 35. Operating temperature range spans from -55°C to 150°C.

It is surface mount type and conforms to the AEC-Q101 automotive standard. The transistor is designed for single transistor configuration with NPN polarity. Compact package dimensions measure 3 mm length, 2.5 mm width, and 1.1 mm height.

Applicable in industrial, automotive, consumer electronics, and laboratory use cases. Explore the Bipolar Transistors category at EnvMart to find compatible components and accessories.
