Vishay Fast Recovery Switching Diode 200 V 70 A 2-Pin T-Module VS-T70HFL20S02

Vishay VS-T70HFL20S02 is a fast recovery switching diode module designed for industrial and power electronics applications. This single-diode T-module incorporates a fast recovery diode with a maximum continuous forward current of 70 A and peak reverse repetitive voltage of 200 V.

The module features an electrically isolated base plate, enabling compact and simplified mechanical designs by mounting multiple modules on a common heatsink. The package is a standard JEDEC-compliant 2-pin T-module that simplifies installation and rapid assembly.

With a peak forward surge current rating of 870 A and a maximum operating temperature of 125°C, this diode module can withstand transient overloads and harsh operating conditions prevalent in motor control, inverters, and DC chopper circuits. The diode’s fast recovery time of 200 ns improves switching performance, reducing losses in power conversion systems.

Additional benefits include large creepage distances for enhanced electrical safety, RoHS compliance, and industrial qualification ensuring reliability and durability. This diode module is suitable for use as a freewheel diode in conjunction with thyristor modules, especially in self-commutated inverter systems, inductive heating, and electronic welding equipment.

Fast recovery time minimizes switching losses. Electrically isolated base plate for easy heat dissipation and installation. Compact panel mount T-module format. High peak surge current capacity supports transient conditions.

Wide operating temperature range from -40°C to 125°C. RoHS certified ensuring environmental compliance. Industrial grade quality with UL E78996 approval. Designed for power switching and fast recovery applications. Explore the full Vishay diode and rectifier module range on EnvMart for industrial electronics, power management, and automation sectors.
