Fujitsu PCB Power Relay 3V Coil Voltage 5A Switching Current 1 NO JV-3S-KT
Specifications
| Country of Origin | China |
|---|---|
| Brand | Fujitsu |
| Height | 12.8mm |
| Length | 17.8mm |
| Model | JV-3S-KT |
| Width | 10.3mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | JV |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | 1 NO |
| Dielectric strength | 5,000 VAC |
| Minimum Operating Temperature | -40°C |
| Operating Power | 0.112 to 0.13 W |
| Nominal Power | 0.2 to 0.3 W |
| Switching Current | 5A |
| Terminal type | PCB Pin |
| Standards/Approvals | RoHS |
| Coil Resistance | 30Ω |
| Coil Voltage | 3V |
| Switching DC Voltage | 150V dc |
| Switching AC Voltage | 150V ac |
| Coil Power | 300mW |
| Switching Power | 150W |
| Mounting space | 175 mm2 |
| Surge strength | 10,000 V |
Key Features
- Low profile design with compact dimensions for space-saving installation.
- High sensitivity coil requiring an operating power between 0.112 to 0.13 W.
- Silver alloy contact material offering reliable conductivity and durability.
- Wide operating temperature range from -40°C to 70°C ensuring robustness in diverse environments.
- High switching power rating of 150W suitable for a variety of PCB power applications.
- Reinforced insulation system with dielectric strength of 5,000 VAC for enhanced safety.
- Plastic sealed type providing protection against environmental contaminants.
- Mount type is PCB with PCB pin terminals for straightforward integration.
Product Description
Fujitsu JV-3S-KT PCB Power Relay is engineered for efficient power switching applications on printed circuit boards. It features a 3V coil voltage and supports a switching current of 5A with a single normally open contact configuration (1 NO). The relay’s compact and low profile design with dimensions 17.8mm (length) x 12.8mm (height) x 10.3mm (width) allows for space-saving mounting on PCBs.
This power relay offers high sensitivity with an operating power range from 0.112 to 0.13 W, leveraging a silver alloy contact material for superior electrical performance and durability. It reliably operates in harsh environments maintaining performance between -40°C and 70°C.
The device supports 150W switching power at both AC and DC voltages of up to 150V. It is also equipped with a reinforced insulation system providing 8 mm insulation distance, dielectric strength of 5,000 VAC, and can withstand surge strength up to 10,000 V, making it suitable for industrial, electrical, automation, and signal conditioning applications.
With a coil resistance of 30Ω and coil power of 300mW, this relay offers energy-efficient operation. Designed for PCB mounting with PCB pin terminals, it ensures easy installation and integration into control systems.
The relay is RoHS compliant, meeting environmental and safety standards. Its plastic sealed type construction ensures protection from dust and contaminants, enhancing longevity and reliability.
Manufactured in China, the Fujitsu JV-3S-KT PCB Power Relay is ideal for high-quality power relay requirements in industrial automation, electrical equipment, and electronics manufacturing sectors.
Low profile compact design for space-saving PCB integration. High sensitivity coil with low operating power. Silver alloy contacts for reliable electrical conductivity. Wide operating temperature range from -40°C to 70°C.
High switching power capacity of 150W for AC and DC applications. Reinforced insulation with high dielectric and surge strength. Plastic sealed construction for environmental protection. PCB mounting type with PCB pin terminals.
RoHS compliant for safety and environmental standards. Manufactured in China ensuring quality and traceability. Explore the extensive range of Power Relays suitable for industrial automation and signal conditioning at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this model is 3V.
This power relay supports a maximum switching current of 5A.
The dimensions are 17.8mm in length, 12.8mm in height, and 10.3mm in width.
It operates effectively within a temperature range of -40°C to 70°C.
The dielectric strength of this model is 5,000 VAC.
The relay features a single normally open contact configuration (1 NO).
It has a high switching power rating of 150W suitable for various applications.
The coil resistance is 30Ω.
This model is designed for PCB mounting with PCB pin terminals.
The contacts are made of silver alloy, which provides reliable conductivity.
It can withstand a surge strength of up to 10,000 V.
Yes, this relay is RoHS compliant, meeting environmental and safety standards.
