Fujitsu PCB Power Relay 12V Coil Voltage 5A Switching Current 1 NO Contact JV-12-KT

Fujitsu JV-12-KT PCB Power Relay features a 12V coil voltage and supports a switching current of 5A with a single normally open (1 NO) contact configuration, making it ideal for precise power switching tasks on printed circuit boards.

This relay comes in a low-profile, compact package measuring 17.8mm in length, 10.3mm in width, and 12.8mm in height, designed to save space and facilitate easy PCB mounting. The relay operates efficiently within a temperature range of -40°C to 70°C, suitable for demanding electronic environments.

The device is constructed with silver alloy contacts, offering superior conductivity and mechanical durability. It features a reinforced insulation system that provides a dielectric strength of 5,000 VAC and surge voltage resistance up to 10,000 V, ensuring reliable insulation between coil and contacts for enhanced safety and longevity.

With an operating power requirement between 0.112 to 0.13 W and a nominal power of 0.2 to 0.3 W, this relay ensures high sensitivity and low power consumption. The mounting space required is compact at 175 mm², allowing efficient utilization of PCB real estate.

Compliant with RoHS standards, this product supports environmentally responsible manufacturing and usage. The coil resistance is rated at 480Ω with a coil power of 300mW, providing stable and consistent operation.

Low profile and space-saving design suitable for PCB mounting. High sensitivity with operating power between 0.112 to 0.13 W. Reinforced insulation system with 5000 VAC dielectric strength. Silver alloy contact material for durable and reliable conductivity.

Wide operating temperature range from -40°C to 70°C. Compact dimensions for easy PCB integration. Mounting space requirement of 175 mm². RoHS compliant for environmental safety. Surge strength rated at 10,000 V for robust protection.

Ideal for industrial, automation, and electrical control applications.

This power relay is suitable for use in industrial automation, electronic equipment, HVAC controls, and various electrical systems that require reliable switching performance. Designed to deliver consistent operation with high insulation and surge protection, it ensures operational safety and longevity.
