Fujitsu Surface Mount Signal Relay, 5V Coil, 1A Current, SPDT Contact Configuration SY-5-K
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Fujitsu |
| Height | 9.5mm |
| Length | 12.5mm |
| Model | SY-5-K |
| Width | 7.4mm |
| Mount Type | Surface |
| Contact Material | Gold Plated |
| Series | SY |
| Maximum Operating Temperature | 90°C |
| Contact Configuration | SPDT |
| Minimum Operating Temperature | -30°C |
| Switching Current | 1A |
| Terminal type | Solder |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 167Ω |
| Coil Voltage | 5V |
| Switching DC Voltage | 60V dc |
| Switching AC Voltage | 60V ac |
| Coil Power | 150mW |
| Switching Power | 24W |
Key Features
- This relay is designed for surface mount applications, offering compact size and versatility.
- Coil power consumption is 150mW ensuring efficient operation.
- It supports AC and DC switching voltages up to 60V for flexible application use.
- Gold plated contacts provide reliable connectivity with low contact resistance of 100mΩ.
- Operating temperature ranges from -30°C to 90°C, suitable for wide ambient conditions.
- Relay is RoHS compliant, manufactured to high standards in Japan.
- Dielectric strength of 1000 VAC and surge strength of 1500 V ensure robust insulation and durability.
- Compact dimensions of 12.5mm length, 7.4mm width, and 9.5mm height support space-saving designs.
Product Description
Fujitsu SY-5-K is a surface mount signal relay designed for highly reliable switching applications. It features a 5V coil voltage and a maximum switching current of 1A, making it suitable for low power control circuits.
This SPDT (Single Pole Double Throw) relay employs gold plated contacts to ensure low contact resistance and enhanced durability, vital for sensitive electronic operations. Its wide operating temperature range from -30°C to +90°C allows use in diverse industrial environments, including automation, electrical control panels, and signal conditioning systems.
Measuring a compact 12.5 mm in length, 7.4 mm in width, and 9.5 mm in height, the SY-5-K relay is ideal for space-constrained PCB layouts. The solder terminal type facilitates secure and stable PCB mounting while maintaining excellent electrical contact.
The relay adheres to RoHS standards, reflecting commitment to environmental and safety regulations. Its dielectric strength of 1000 VAC (between coil and contacts) and surge strength of 1500 V provide robust insulation and protection against voltage spikes, enhancing operational reliability.
This relay is manufactured in Japan, ensuring high quality and consistent performance. Its coil resistance of 167Ω and coil power rating of 150mW indicate efficient power consumption characteristics.
Compact design with high sensitivity and low power coil consumption. Surface mount relay suitable for industrial and automation uses. Wide operating temperature range for versatile environments. High dielectric and surge strength ensure durability.
Gold plated contacts reduce wear and maintain signal integrity. RoHS compliant and manufactured in Japan for quality assurance. Compatible with AC and DC switching voltages up to 60V. Low contact resistance improves switching reliability.
Solder terminal type enables secure PCB installation. Ideal for use in electrical, industrial control, and signal conditioning applications. Explore the Fujitsu range of Signal Relays and other electronic components on EnvMart for reliable and high-performance electrical solutions.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The coil voltage of this relay is 5V.
The maximum switching current for the SY-5-K relay is 1A.
This model has dimensions of 12.5mm in length, 7.4mm in width, and 9.5mm in height.
The contact configuration of the SY-5-K relay is SPDT (Single Pole Double Throw).
The contact resistance for this relay is 100mΩ.
The operating temperature range for the SY-5-K relay is from -30°C to +90°C.
This relay uses a surface mount type for installation.
The coil power consumption of the SY-5-K relay is 150mW.
It can switch AC and DC voltages up to 60V.
The contacts of the SY-5-K relay are made of gold plated material.
Yes, this relay is RoHS compliant, adhering to environmental and safety regulations.
The dielectric strength of this relay is 1000 VAC, with a surge strength of 1500 V.
