Fujitsu PCB Power Relay 9V Coil Voltage 10A Switching Current Silver Alloy Contacts FTR-H2AL009T
Specifications
| Country of Origin | China |
|---|---|
| Brand | Fujitsu |
| Height | 25mm |
| Length | 24mm |
| Model | FTR-H2AL009T |
| Width | 11mm |
| Mount Type | PCB |
| Contact Material | Silver Alloy |
| Series | FTR-H2 |
| Maximum Operating Temperature | 70°C |
| Contact Configuration | 1 NO |
| Dielectric strength | 4KV |
| Minimum Operating Temperature | -40°C |
| Switching Current | 10A |
| Terminal type | PCB Pin |
| Standards/Approvals | RoHS |
| Coil Resistance | 155Ω |
| Coil Voltage | 9V |
| Switching DC Voltage | 300V dc |
| Switching AC Voltage | 300V ac |
| Coil Power | 250mW |
| Switching Power | 300W |
| Surge strength | 10KV |
| Insulation distance | minimum 6mm between coil and contact |
Key Features
- Operates within a temperature range of -40°C to 70°C ensuring high reliability.
- Compact dimensions of 24mm length, 11mm width, and 25mm height save PCB space by 26% compared to earlier models.
- Silver alloy contacts resist corrosion and offer excellent conductivity.
- Offers switching power capacity of 300W with both AC and DC switching voltages rated up to 300V.
- High insulation distance of minimum 6mm between coil and contact for safety.
- Dielectric strength rated at 4KV and surge strength at 10KV for robust operation.
- RoHS compliant with cadmium-free contacts supporting eco-friendly standards.
- Coil resistance of 155 ohms and coil power consumption of 250mW for energy efficiency.
Product Description
Fujitsu FTR-H2AL009T is a PCB Power Relay designed primarily for electronic and electrical applications that demand reliable switching performance and compact size. Featuring a 9V coil voltage and a 10A switching current, this relay is ideal for industrial Automation, Control Systems, and Signal Conditioning circuits.
Its compact size (24mm length, 11mm width, 25mm height) allows high-density mounting, saving approximately 26% PCB space compared to the previous FTR-H1 series. The silver alloy contacts ensure high conductivity and corrosion resistance, which contribute to consistent electrical performance across varied operating conditions.
This relay is rated for switching both AC and DC voltages up to 300V, with a maximum switching power of 300W. It supports a robust temperature range from -40°C to 70°C, making it suitable for demanding environments. The insulation distance between the coil and contacts is a minimum of 6mm, assuring high insulation and safety standards.
The relay boasts dielectric strength of 4KV and surge strength of 10KV, protecting the device and circuit against high voltage spikes. Energy-efficient coil resistance of 155 ohms and power consumption of 250mW make the relay ideal for sustained operations in control systems.
Constructed with environmental considerations, the contact material is cadmium-free and the relay complies with RoHS directives, which ensures hazardous substances are minimized.
This product originates from China and supports a wide range of industrial applications including Electrical Equipment, Manufacturing Automation, Power Control Systems, and other commercial electronic assemblies requiring durable PCB mounting relays.
Operates within -40°C to 70°C for reliable performance. Compact size with high-density mounting saving 26% PCB space. Silver alloy contacts for superior conductivity and corrosion resistance. Switching power rated at 300W for AC/DC voltages up to 300V.
High insulation with 6mm distance between coil and contact. Dielectric strength of 4KV and surge strength of 10KV for protection. Energy efficient coil power consumption of 250mW. RoHS compliant with cadmium-free contacts supporting environmental standards.
Explore a broad selection of Power Relays at EnvMart for diverse control and automation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The FTR-H2AL009T relay has a switching current rating of 10A.
This model operates with a coil voltage of 9V.
It offers a maximum switching power capacity of 300W.
The dimensions of this relay are 24mm in length, 11mm in width, and 25mm in height.
The dielectric strength of the FTR-H2AL009T is rated at 4KV.
It features silver alloy contacts, which provide excellent conductivity and corrosion resistance.
This relay operates within a temperature range of -40°C to 70°C.
The minimum insulation distance between the coil and contact is 6mm.
This relay is rated for switching voltages up to 300V for both AC and DC applications.
The coil resistance for this relay is 155 ohms.
The surge strength of the FTR-H2AL009T is rated at 10KV.
Yes, this relay is RoHS compliant, featuring cadmium-free contacts to support environmental standards.
