Fujitsu Surface Mount Signal Relay, 5V DC Coil, 2A Switching Current, DPDT Contact Configuration RY-5W-K
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Fujitsu |
| Height | 12.5mm |
| Length | 20.2mm |
| Model | RY-5W-K |
| Width | 9.8mm |
| Mount Type | Surface |
| Contact Material | Gold Plated |
| Series | RY |
| Maximum Operating Temperature | 90°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -30°C |
| Switching Current | 2A |
| Terminal type | Solder |
| Contact Resistance | 100mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 1029Ω |
| Coil Voltage | 5V dc |
| Switching DC Voltage | 60V dc |
| Switching AC Voltage | 60V ac |
| Coil Power | 150mW |
| Switching Power | 24W |
Key Features
- The relay has a DPDT (Double Pole Double Throw) contact configuration.
- It operates with a coil power consumption of 150mW and coil resistance of 1029Ω.
- Designed for surface mount with solder terminal type ensuring reliable electrical connections.
- Its switching power rating is 24W, with a maximum switching voltage of 60V AC/DC and switching current up to 2A.
- The contact material is gold plated to provide low contact resistance and high reliability.
- Operates in a temperature range from -30°C minimum to 90°C maximum.
- The compact physical dimensions measure approximately 20.2mm in length, 12.5mm in height, and 9.8mm in width.
- Surge strength is rated at 1500V ensuring protection against voltage spikes.
Product Description
Fujitsu RY-5W-K is a surface mount signal relay designed for precision switching control in electronics, automation, and electrical applications. It features a 5V DC coil voltage and supports a switching current of 2A with DPDT contact configuration, suitable for double pole double throw switching needs.
The relay offers robust performance with a coil power consumption of 150mW and coil resistance of 1029Ω. It operates reliably over a wide temperature range from -30°C to 90°C, making it suitable for industrial, laboratory, and automation environments.
This model is characterized by gold plated contacts ensuring low contact resistance (100mΩ) and high reliability under frequent switching operations. It supports switching voltages up to 60V AC or DC with a maximum switching power of 24W. The relay is compact, measuring 20.2mm length, 12.5mm height, and 9.8mm width, and is designed for surface mounting with solder terminals for secure installation.
The surge strength of 1,500V protects the relay from voltage spikes, enhancing durability in demanding applications. Fujitsu's RY series ensures high dielectric strength and stable switching performance.
The DPDT contact configuration allows changing of two circuits simultaneously. Gold plated contacts provide long service life and consistent conductivity. Widely used in industrial controls, automation systems, signal conditioning, and other precision electronics.
Compact size and surface mount design allow easy integration into PCB layouts. Constructed according to RoHS compliance to meet environmental and safety standards.
This product is manufactured in Japan, ensuring high quality and reliability standards. It is ideal for professionals needing dependable relays for signal switching and control tasks in industrial, automation, and electrical engineering applications.
Browse the Signal Relay category at EnvMart for more specialized relay components from Fujitsu and other leading manufacturers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay operates with a coil voltage of 5V DC.
It supports a maximum switching current of 2A.
This model features a DPDT (Double Pole Double Throw) contact configuration.
The surge strength is rated at 1500V, providing protection against voltage spikes.
It measures approximately 20.2mm in length, 12.5mm in height, and 9.8mm in width.
The coil power consumption is 150mW.
It operates reliably within a temperature range from -30°C to 90°C.
It features solder terminals for secure installation.
The contacts are made of gold plated material, ensuring low contact resistance.
The relay supports a maximum switching voltage of 60V for both AC and DC.
The contact resistance is rated at 100mΩ, providing high reliability.
Yes, this relay is constructed according to RoHS compliance standards.
