Vishay Schottky Diode 30 V 1 A DO-214AA Surface Mount VS-MBRS130LTRPBF
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 2.39mm |
| Brand | Vishay |
| Height | 2.56mm |
| Length | 4.57mm |
| Model | VS-MBRS130LTRPBF |
| Width | 3.81mm |
| Mount Type | Surface |
| Series | VSX |
| Maximum Operating Temperature | 125°C |
| Package Type | DO-214AA |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Maximum Continuous Forward Current If | 1A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 230A |
| Maximum Forward Voltage Vf | 0.3V |
Key Features
- This diode supports a maximum continuous forward current of 1 ampere.
- It has a peak reverse repetitive voltage of 30 volts ensuring reliable operation under reverse voltage conditions.
- The diode features a very low maximum forward voltage of 0.3 volts, reducing power loss during conduction.
- Suitable for operation in temperatures ranging from -55°C up to 125°C.
- The diode has a fast switching characteristic with a peak non-repetitive forward surge current of 230 amperes.
- Its compact DO-214AA package offers dimensions of 4.57 mm length, 3.81 mm width, and 2.56 mm height.
- This device is a single diode configuration with 2 pins for surface mounting.
- No automotive standard or specific approvals are indicated for this model.
Product Description
Vishay VS-MBRS130LTRPBF Schottky Diode is engineered for applications requiring efficient rectification with low forward voltage drop and fast switching capabilities. This 30 V 1 A diode in DO-214AA package offers reliable performance in power management and signal rectification tasks within industrial, electronic, automotive, and telecommunications equipment.
The surface mount package ensures easy PCB integration with two pins and compact dimensions of 4.57 mm length, 3.81 mm width, and 2.56 mm height. The diode’s peak reverse repetitive voltage rating of 30 V and maximum continuous forward current of 1 A guarantee its suitability for medium power level circuits.
Operating temperature ranges from -55°C to 125°C make it robust under varied environmental conditions. With a peak non-repetitive forward surge current rating of 230 A, it can handle high transient currents without damage. The maximum forward voltage of 0.3 V minimizes power losses enhancing overall efficiency in circuit designs.
Commonly used in switching power supplies, voltage clamping, and freewheeling diode roles, this Schottky diode eliminates the issues related to slow recovery times common in standard diodes.
This diode supports a maximum continuous forward current of 1 ampere. It has a peak reverse repetitive voltage of 30 volts ensuring reliable operation under reverse voltage conditions. The diode features a very low maximum forward voltage of 0.3 volts, reducing power loss during conduction.
Suitable for operation in temperatures ranging from -55°C up to 125°C. The diode has a fast switching characteristic with a peak non-repetitive forward surge current of 230 amperes. Its compact DO-214AA package offers dimensions of 4.57 mm length, 3.81 mm width, and 2.56 mm height.
This device is a single diode configuration with 2 pins for surface mounting. No automotive standard or specific approvals are indicated for this model.
This component is ideal for industrial electronic designs, telecommunications, and power circuits requiring efficient rectification with minimized forward voltage drop and reduced switching losses. Vishay’s Schottky diode technology ensures outstanding performance and reliability.
Explore the Vishay range of Schottky Diodes & Rectifiers at EnvMart for quality, precision, and industrial applications.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of this Schottky diode is 1 ampere.
The maximum forward voltage of this diode is 0.3 volts, which helps reduce power loss during conduction.
The dimensions of the DO-214AA package are 4.57 mm in length, 3.81 mm in width, and 2.56 mm in height.
This diode operates within a temperature range of -55°C to 125°C.
The peak non-repetitive forward surge current rating is 230 amperes, allowing it to handle high transient currents without damage.
This diode has a configuration of 2 pins for surface mounting.
This diode is a Schottky rectifier, which is known for its low forward voltage drop and fast switching capabilities.
This Schottky diode is commonly used in switching power supplies, voltage clamping, and as a freewheeling diode.
The country of origin for this product is India.
This model features a single diode configuration.
