Vishay Film Capacitor 220 nF 200V AC 630V DC Through Hole MKT1813422015

Vishay MKT1813422015 Film Capacitor offers 220 nF capacitance with voltage ratings of 200 V AC and 630 V DC designed for through hole mounting applications.

It utilizes metallised polyester film technology to provide excellent electrical characteristics including high insulation resistance and low dissipation factor, making it highly suitable for demanding electronic circuits.

This capacitor features a lead pitch of 26.5 mm and pin diameter of 0.7 mm designed to fit standard through hole PCB layouts. The maximum operating temperature of 100°C ensures stable operation under moderate thermal conditions.

Its compact form factor with dimensions 14 mm in length and 8 mm in width allows integration into space-constrained assemblies. Compliant with RoHS environmental directives, it supports eco-friendly manufacturing and application.

Typical uses include blocking unwanted signals, bypassing noise, filtering frequencies, timing circuits, coupling signals, decoupling power lines, and interference suppression in low voltage electronic systems.

Constructed with metallised polyester film for durability and stability. Rated maximum operating temperature of 100°C ensuring reliable performance. Lead pitch of 26.5 mm suitable for through hole PCB mounting. Pin count of 2 with lead diameter 0.7 mm for secure connections.

Compliant with RoHS standards for environmental safety. Compact dimensions: 14 mm length and 8 mm width facilitating space-saving designs. Applications include blocking, bypassing, filtering, timing, coupling, decoupling, and interference suppression in low voltage circuits.
