| Country of Origin | India |
|---|---|
| Brand | onsemi |
| Height | 1.11mm |
| Length | 3.04mm |
| Model | MMBD352LT1G |
| Width | 1.4mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Sub Type | Silicon Junction |
| Minimum Operating Temperature | -55°C |
| Standards/Approvals | RoHS, Pb-Free |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 300mW |
| Diode Configuration | Series |
| Maximum Forward Voltage Vf | 600mV |
| Maximum Peak Reverse Repetitive Voltage Vrrm | 7V |
onsemi MMBD352LT1G is a high-reliability switching diode featuring a silicon junction and housed in a compact 3-pin SOT-23 surface mount package. It is specifically designed for RF band operation in high-frequency, radio frequency, and microwave mixing and detection applications. This diode delivers robust performance with a maximum peak reverse repetitive voltage of 7 V and maximum power dissipation of 300mW, ensuring stable operation under demanding thermal and electrical conditions.
The diode has a maximum forward voltage of 600mV that supports efficient switching, and its operating temperature range from -55°C to 150°C accommodates a wide variety of industrial and automotive environments. Its dimensions of 3.04 mm length, 1.4 mm width, and 1.11 mm height enable space-saving PCB layouts in compact electronic designs.
Additionally, it carries the AEC-Q101 automotive qualification standard, making it suitable for use in advanced automotive electronic systems requiring high reliability and quality assurance.
The device’s small form factor and electrical characteristics make it ideal for use in switching applications in industrial, automotive, communications, and consumer electronics sectors. Its surface mount design optimizes production processes by allowing automated insertion into machinery, improving efficiency and consistency of assembly.
Silicon junction diode construction optimized for switching applications. Compact 3-pin SOT-23 surface mount package minimizes PCB space. Handles up to 300mW power dissipation. Rated for maximum peak reverse voltage of 7 V.
Low forward voltage drop of 600mV increases efficiency. Wide operating temperature range from -55°C to 150°C. RoHS and Pb-Free compliant for environmentally safe applications. Meets AEC-Q101 automotive quality standards.
This onsemi switching diode MMBD352LT1G is supported by comprehensive technical documentation and 3D mechanical models, facilitating easy integration into diverse system designs. Explore the Semiconductor category at EnvMart for related Switching Diodes and components to suit your electronic design needs.
