Texas Instruments Operational Amplifier 1 MHz 14-Pin SOIC 18V LM348D
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Texas Instruments |
| Height | 1.58mm |
| Length | 8.65mm |
| Model | LM348D |
| Width | 3.91mm |
| Mount Type | Surface |
| Series | LM348 |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Number Of Channels | 4 |
| Pin Count | 14 |
| Maximum Supply Voltage | 18V |
| Minimum Supply Voltage | 4V |
| GBP - Gain Bandwidth Product | 1MHz |
| Input Bias Current | 400 nA |
| Vos - Input Offset Voltage | 6 mV |
| Slew Rate | 0.5V/μs |
| Input Offset Current | 100 nA |
| LM348D Texas Instruments, Op Amp, 1MHz, 14-Pin SOICBrand | Texas Instruments |
Key Features
- Surface mount SOIC package suitable for compact PCB designs.
- Four channels capable of independent operation.
- Operates with supply voltage range from 4V to 18V.
- Maximum operating temperature of 70°C ensuring reliable performance.
- Low input bias current of 400 nA for precision applications.
- Slew rate of 0.5 V/μs ensures adequate response speed.
- Input offset voltage of 6 mV allows for accurate amplification.
- Compact dimensions of 8.65 mm length and 3.91 mm width.
Product Description
Texas Instruments LM348D is a versatile operational amplifier designed for a wide range of electronics applications requiring precise analog signal processing. This device features four independent amplifier channels integrated within a compact 14-Pin SOIC surface mount package, delivering reliable performance within industrial and laboratory electronics.
The LM348D operates efficiently over a supply voltage range of 4V to 18V and can function accurately within an ambient temperature between 0°C and 70°C. Its 1 MHz gain bandwidth product coupled with a slew rate of 0.5 V/μs makes it suitable for moderate frequency analog applications.
In applications demanding low offset and bias currents, the LM348D excels with an input offset voltage of 6 mV and input bias current of 400 nA. These characteristics make it ideal for precision amplification tasks across instrumentation, measurement equipment, signal conditioning, and control systems.
The compact 14-Pin SOIC surface mount package measures 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height, optimizing board space usage and supporting modern manufacturing techniques. Designed and manufactured in Malaysia, the LM348D ensures compliance with quality manufacturing standards.
Surface mount package for space-efficient PCB layouts. Four independent amplifier channels. Wide supply voltage range of 4V to 18V. Operating temperature range from 0°C to 70°C. Low input bias current and offset voltage for precision operation.
1 MHz gain bandwidth product suited for general-purpose amplification. Slew rate of 0.5 V/μs facilitating moderate frequency signals. Compact 14-Pin SOIC package dimensions. Manufactured in Malaysia ensuring consistent quality.
This Operational Amplifier series is well suited for industrial, laboratory, and commercial electronics, including control and measurement instruments, audio and signal processing devices, and general analog circuit design.
Explore EnvMart's extensive catalog of electronic components to find compatible amplifiers, semiconductors, and other critical parts for your project’s success.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1 MHz, making it suitable for general-purpose amplification tasks.
It operates efficiently over a supply voltage range from 4V to 18V.
This model features four independent amplifier channels, allowing for versatile applications in electronic circuits.
The compact dimensions of this operational amplifier are 8.65 mm in length, 3.91 mm in width, and 1.58 mm in height.
The maximum operating temperature is 70°C, ensuring reliable performance in various conditions.
It has an input offset voltage of 6 mV, which allows for accurate amplification in precision applications.
The slew rate of this model is 0.5 V/μs, facilitating adequate response speed for moderate frequency signals.
The input bias current is 400 nA, which is beneficial for applications requiring low bias current.
It comes in a 14-Pin SOIC surface mount package, suitable for compact PCB designs.
The minimum operating temperature is 0°C, allowing it to function in a range of ambient conditions.
This operational amplifier is well-suited for industrial, laboratory, and commercial electronics, including control and measurement instruments, and audio processing devices.
The input offset current is 100 nA, which contributes to its precision in amplification tasks.
