Molex MicroClasp Series Shrouded Straight Through Hole PCB Header, 6 Contacts, 2 mm Pitch, 1 Row 55932-0630

Molex 55932-0630 MicroClasp Series shrouded straight through hole PCB header is engineered for wire-to-board applications requiring compact, reliable, and secure connections. Featuring 6 male contacts arranged in a single row with a 2 mm pitch, this connector supports currents up to 3 A and voltages up to 250 V, making it suitable for a wide range of industrial, commercial, and electronic component assemblies.

The polyester housing provides robust insulation and mechanical stability, while its shrouded design ensures secure mating retention with an audible click and latch protection mechanism to prevent accidental disconnections. The innovative MicroClasp terminal design facilitates low insertion and withdrawal forces, enhancing ease of use in assembly and maintenance.

Operating reliably in temperatures from -40°C to 105°C, this PCB Header suits harsh environments found in industrial automation, power supplies, instrumentation, and telecommunications equipment. The termination method is solder, with tin-plated male contacts ensuring optimal electrical conductivity and corrosion resistance. Through hole mounting offers mechanical durability and stable electrical connections for printed circuit boards.

Typical applications include power and signal routing in electronic assemblies, embedded systems, and equipment requiring compact wire-to-board interfaces. The 3.2 mm tail pin length combined with 2 mm mating pin length provides secure and precise engagement, accredited for high-cycle mating reliability.

The Molex MicroClasp connector family is known for space-saving design due to its 2.0 mm pitch, competitive to 2.00 mm and 2.50 mm systems, combined with a unique inner positive lock mechanism that assures connector retention and user confidence during operation.

Compact 2.00 mm pitch MicroClasp design enables PCB space savings. Shrouded housing offers secure mating and latch protection with audible click. Male contacts with tin plating ensure reliable solder termination. Current rating up to 3 A for moderate power electronic applications.

Operating temperature range from -40°C to 105°C suitable for harsh environments. Through hole mounting provides robust mechanical and electrical connection. Polyester housing material delivers durable insulation and chemical resistance.

Low insertion force contact design facilitates easy mating and unmating cycles. Tail pin length of 3.2 mm and mating pin length of 2 mm ensure secure contact interface. Manufactured in Japan with high quality standards for industrial and commercial PCB assemblies.

This product is ideal for use in industrial, laboratory, manufacturing, electronic assembly, instrumentation, and telecommunications applications. Explore Molex connectors and related PCB hardware in the Electronics Components category at EnvMart.
