Molex Pico-Clasp Series Right Angle Surface PCB Header 8 Contact 1 mm Pitch 1 Row Shrouded 501568-0807

Molex 501568-0807 Pico-Clasp Series Right Angle Surface PCB Header is a high-density, compact wire-to-board connector system designed for efficient and reliable PCB interfacing. This model is a single row, 8 contact connector with a 1 mm pitch, tailored for applications requiring precise spacing and secure connections.

The connector features a robust nylon housing that guarantees electrical insulation and mechanical protection. Brass contacts plated with tin ensure optimal electrical performance and durability over repeated mating cycles. The shrouded design provides an added layer of protection and mechanical stability, minimizing the risk of damage and misalignment during connection.

This connector operates at a rated current of 1A and a voltage of 50V, suitable for a wide array of low-current electronic devices. The right-angle orientation facilitates compact PCB layouts, making it ideal for densely populated electronic assemblies in industrial, manufacturing, and commercial electronic products.

Its operating temperature span from -40°C to 105°C allows reliable performance in harsh and variable environmental conditions. The solder termination type supports effective, long-lasting mounting on circuit boards using surface mount technology.

The 1 mm pitch and single row configuration make it compatible with a variety of PCB designs, enabling engineers to create high-density and reliable interconnections. The inclusion of a positive locking mechanism further ensures secure cable retention during operation, minimizing the risk of disconnection in critical systems.

Manufactured in Japan, the Molex Pico-Clasp 501568-0807 meets exacting quality and performance standards required in modern electronics manufacturing. It is widely used in applications including communication equipment, industrial control systems, and consumer electronics where space and reliability are paramount.

This connector features a 1.00 mm pitch single row with 8 contacts for compact PCB applications. Constructed with durable nylon housing and brass contacts plated with tin for optimum conductivity. Designed for surface mount on PCBs with right-angle orientation to suit compact layouts.

Operates with a current rating of 1A and a voltage rating of 50V for low power connections. Shrouded connector system includes positive lock to ensure secure mating without accidental disconnection. Contact mating pin length is 1 mm and the connector supports solder termination type.

Operating temperature range from -40°C to 105°C suits industrial and commercial electronic applications. Manufactured in Japan ensuring high-quality standards and reliability. Explore the extensive range of PCB Headers and Connectors on EnvMart to find compatible solutions for your electronic assembly requirements.
