Molex MicroClasp Series Right Angle Through Hole PCB Header, 10 Contact, 2 mm Pitch, 2 Row, Shrouded 55959-1030

Molex 55959-1030 MicroClasp Series Right Angle Through Hole PCB Header is a precision electronic component designed for wire-to-board connection with 10 contacts arranged in 2 rows. Featuring a 2.00 mm pitch and shrouded design, it is optimized for secure and reliable mating. This right angle header offers flexibility in PCB layout where vertical clearance and space savings are critical.

The housing material is robust polyester that provides excellent insulation and mechanical stability. Contacts are made from brass with tin plating to ensure optimal electrical conductivity and resistance to corrosion. Termination is designed for solder mounting on through hole PCBs, ensuring strong mechanical and electrical connections suitable for industrial and commercial electronics.

This component supports up to 3 A current at 250 V, allowing it to be used in a wide range of low to medium power electronic circuits. Its operating temperature range from -40°C to 105°C makes it suitable for environments with temperature variations. The MicroClasp series also features a unique inner positive locking mechanism that secures the housing with an audible click, ensuring assembly integrity.

The design incorporates low insertion and withdrawal forces, reducing wear during repeated connections. Additional features include a housing lance system for further secure retention and a two-point contact system that enhances electrical reliability. The compact 2 mm pitch layout aids in PCB space management, making it ideal for dense board designs in industrial, consumer, and communication electronics applications.

Applications include circuit boards in industrial machinery, instrumentation, communication devices, and other electronic systems where reliable wire-to-board connections are required with easy mating and unmating functionality. The product is manufactured in Japan, assuring high quality standards. Packaging allows efficient handling and insertion into assembly processes.

The header features a right angle orientation for PCB mounting flexibility. Designed with a durable polyester housing for reliable insulation. Supports a current rating of up to 3 amps at 250 volts. Brass contacts plated with tin ensure good conductivity and corrosion resistance.

Includes a unique inner positive lock for secure retention and audible mating click. Low insertion force terminal design reduces wear during assembly. Operating temperature range from -40°C to 105°C allows use in varied environments.

Mount type is through hole with solder termination for stable mounting. Compact 2 mm pitch allows PCB space savings in dense electronic designs. Tail pin length is 3.2 mm and mating pin length is 2 mm for effective connections.
