Wurth Elektronik FPC Connector 0.5 mm Pitch 30 Way Straight Male Solder Pin 68713014522

Wurth Elektronik 68713014522 is a 0.5 mm pitch FPC Connector featuring 30 contacts and a straight male configuration designed for wire-to-board SMT applications. It utilizes a Zero Insertion Force (ZIF) mechanism to facilitate easy insertion and removal of flexible printed circuits, minimizing wear and tear on the connector and cable. The connector is rated for 500mA current and operates up to 50 volts, suitable for low power electronic devices requiring compact board space.

The contacts are manufactured from phosphor bronze with a tin over nickel plating, offering reliable conductivity and corrosion resistance. The connector housing is made from liquid crystal polymer, providing mechanical strength and a UL94-V0 flammability rating that ensures safety in industrial and commercial environments.

The horizontal, bottom contact design allows for a low profile integration into PCB layouts, making it ideal for compact electronic assemblies. It supports 25 mating cycles, ensuring durability for repeated use in prototype development or production environments.

Operating temperature ranges from -25°C to 85°C, allowing use in diverse climatic conditions. The locking mechanism secures the cable firmly to prevent accidental disconnection, enhancing reliability during device operation.

This Wurth Elektronik FPC Connector is widely applicable in consumer electronics, laboratories, industrial control systems, and embedded computing where space-saving and reliable connections are critical. It complies with essential mechanical and safety standards, although specific certification details are not provided.

Features a surface mount type with a bottom contact position for secure connections. Constructed with phosphor bronze contacts plated with tin over nickel for durability. Supports a current of 500mA and a voltage rating of 50V.

Incorporates Zero Insertion Force (ZIF) design for ease of assembly and improved connector life. Operates within a temperature range of -25°C to 85°C, suitable for varied environments. Includes a locking mechanism and is designed with liquid crystal polymer housing for flame resistance.

This model supports 25 mating cycles and has a UL94-V0 flammability rating. Explore Wurth Elektronik connectors and FPC Connector options in EnvMart for precise, reliable solutions tailored to industrial and electronic manufacturing applications.
