Wurth Elektronik FPC Connector 686 Series 1 mm Pitch 30 Way Straight Male Solder Pin 68613014122
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 125V |
| Brand | Wurth Elektronik |
| Orientation | Straight |
| Current | 1A |
| Mount Type | Surface |
| Housing Material | Polyphenylene Sulphide |
| Contact Material | Phosphor Bronze |
| Series | 686 |
| Termination Type | Solder Pin |
| Maximum Operating Temperature | 85°C |
| Sub Type | Wire-to-Board |
| Minimum Operating Temperature | -25°C |
| Number of Rows | 1 |
| Pitch | 1mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 30 |
| Contact Gender | Male |
| Connector Gender | Male |
| Insertion Force | ZIF |
| Contact Position | Top |
Key Features
- The connector has 30 contacts made of phosphor bronze material for high reliability.
- It uses a Zero Insertion Force (ZIF) type insertion with a locking mechanism ensuring easy connection and secure locking.
- This connector has a voltage rating of 125V and is suitable for currents up to 1A.
- Operating temperature ranges from -25°C to 85°C, making it suitable for various environments.
- The housing is constructed from durable polyphenylene sulphide with contact plating of tin over nickel.
- Its top contact position and straight orientation provide compact and efficient layout options.
- The connector series is 686, meeting industry standards without specific approvals.
Product Description
Wurth Elektronik 68613014122 FPC Connector is a high-quality 30 way straight male connector with 1 mm pitch designed for wire-to-board applications in electronic and power connector systems. It supports a current of 1A and a voltage rating of 125V, suitable for a broad range of industrial and commercial uses.
This connector features phosphor bronze contacts with tin over nickel plating for optimized conductivity and corrosion resistance. The housing is made from polyphenylene sulphide, providing excellent mechanical strength and thermal stability with an operating temperature range from -25°C to 85°C.
The 686 series connector implements Zero Insertion Force (ZIF) technology combined with a locking mechanism for secure and easy mating. Its top contact position with straight orientation allows for compact PCB designs and high mating cycles, enhancing durability in demanding environments.
Ideal for industrial electronics, manufacturing equipment, and compact assembly applications, this connector provides reliable connectivity for FPC/FFC cables. Although there are no specific industry approvals, the robust construction and high-quality materials meet typical electronic component standards.
The connector has 30 contacts with phosphor bronze material. Zero Insertion Force insertion and locking mechanism ensure ease of use and security. Voltage rating of 125V and current carrying capacity of 1A. Housing made of polyphenylene sulphide with high thermal tolerance.
Tinned nickel plating on contacts for corrosion resistance. Top contact and straight orientation supports compact layouts. Operating temperature range from -25°C to 85°C.
This product is part of the 686 series from Wurth Elektronik, suitable for electronics manufacturing, power connectors, and PCB connector systems. Browse more FPC Connectors and related components in the EnvMart catalog for diverse industrial applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this connector is 125V.
It supports a current of up to 1A.
The operating temperature range is from -25°C to 85°C.
The housing is made from polyphenylene sulphide, and the contacts are made of phosphor bronze with tin over nickel plating.
This connector has 30 contacts.
It uses a solder pin termination type.
The connector has a straight orientation.
It features a Zero Insertion Force (ZIF) insertion mechanism with a locking mechanism for secure mating.
This connector is part of the 686 series.
Yes, it is designed for surface mounting applications.
It is suitable for wire-to-board applications in electronic and power connector systems.
The country of origin for this connector is India.
