DiodesZetex NPN Bipolar Transistor 3 A 100 V 3-Pin SOT-23 ZXTN25100BFHTA

DiodesZetex ZXTN25100BFHTA is a high-performance NPN bipolar transistor specially designed for applications requiring robust current handling and voltage resistance. Encased in a compact 3-pin SOT-23 surface mount package, this transistor supports a maximum collector current of 3 A and can withstand collector-emitter voltages up to 100 V. It suits general purpose amplification and switching tasks in industrial, automotive, and electronic circuit designs.

The transistor features a single NPN configuration with a minimum DC current gain (hFE) of 50, ensuring efficient signal amplification. Its maximum power dissipation rating of 1.81 W allows reliable operation while controlling thermal conditions. With a maximum transition frequency (ft) of 160 MHz, it supports high-speed switching essential for modern electronics. The wide operating temperature range from -55 °C up to 150 °C makes it suitable for harsh environments, including automotive electronics where AEC-Q101 standards are critical.

Physical dimensions of 3 mm (length) by 2.5 mm (width) and a height of 1.1 mm, coupled with surface mount technology (SMT) compatibility, enable compact PCB layouts and automated assembly line processing. Its Germany origin assures stringent quality controls and consistency in performance.

Maximum DC collector current of 3 A for demanding load applications. Maximum collector-emitter voltage of 100 V provides high voltage tolerance. Single NPN transistor configuration offers versatile electronic uses. Compact SOT-23 surface mount package supports efficient PCB integration.

Rated for power dissipation of 1.81 W to maintain thermal stability. High frequency cutoff at 160 MHz ensures rapid switching capability. Operates reliably from -55 °C to 150 °C temperature range. Automotive qualified per AEC-Q101 standards for stringent quality.

Precise physical dimensions of 3 mm x 2.5 mm x 1.1 mm for space-saving designs. Manufactured in Germany ensuring premium build quality.

This transistor is widely used in automotive electronics, industrial machinery control systems, consumer electronics, and other applications demanding reliable high current switching with compact form factor. For additional information and technical support, consider browsing the Bipolar Transistors category at EnvMart.
