DiodesZetex Digital Transistor NPN 50 mA 50 V 200 mW 3-Pin SOT-23 Surface Mount DDTC114ECA-7-F

Name: DiodesZetex Digital Transistor NPN 50 mA 50 V 200 mW 3-Pin SOT-23 Surface Mount DDTC114ECA-7-F
Brand: DiodesZetex
SKU: 129684
Price: 0.03 USD
Availability: InStock



Category Digital Transistor Brand DiodesZetex Condition New

Specifications

Country of Origin	China
Brand	DiodesZetex
Height	1.1mm
Length	3mm
Model	DDTC114ECA-7-F
Width	1.4mm
Mount Type	Surface
Series	DDTC
Maximum Operating Temperature	150°C
Package Type	SOT-23
Minimum Operating Temperature	-55°C
Pin Count	3
Maximum Collector Emitter Voltage Vceo	50V
Minimum DC Current Gain hFE	30
Transistor Polarity	NPN
Automotive Standard	AEC-Q101
Maximum Power Dissipation Pd	200mW
Maximum DC Collector Current Idc	50mA
Transistor Configuration	Single
Maximum Transition Frequency ft	250MHz

Key Features

Operates with a maximum collector current of 50 mA.
Maximum collector-emitter voltage rating is 50 V.
Compact SOT-23 package with 3 pins, suitable for surface mounting.
Maximum power dissipation of 200 mW ensures reliable operation.
NPN transistor configuration ideal for digital switching applications.
Minimum DC current gain (hFE) of 30 for effective amplification.
Transition frequency up to 250 MHz supports high-speed switching.
Wide operating temperature range from -55°C to 150°C for harsh environments.

Product Description

DiodesZetex DDTC114ECA-7-F is a digital transistor featuring integrated resistors designed to simplify driving from digital sources. It is a single NPN bipolar transistor housed in a compact 3-pin SOT-23 package, optimized for surface mount technology.

The transistor supports a maximum DC collector current of 50 mA and a maximum collector-emitter voltage of 50 V, with a power dissipation of 200 mW, making it suitable for various low-power switching and amplification applications.

With a minimum DC current gain of 30 and a maximum transition frequency of 250 MHz, this device supports efficient and fast switching operations. It operates reliably across a broad temperature range from -55°C up to 150°C, suitable for demanding industrial, automotive, and consumer electronic environments.

Certified to the automotive AEC-Q101 standard, the transistor ensures dependable performance for automotive electronics and other critical applications. Operates with a maximum collector current of 50 mA. Maximum collector-emitter voltage rating is 50 V.

Compact SOT-23 package with 3 pins, suitable for surface mounting. Maximum power dissipation of 200 mW ensures reliable operation. NPN transistor configuration ideal for digital switching applications. Minimum DC current gain (hFE) of 30 for effective amplification.

Transition frequency up to 250 MHz supports high-speed switching. Wide operating temperature range from -55°C to 150°C for harsh environments. Automotive standard compliant (AEC-Q101) ensuring quality and durability.

This digital transistor is ideal for use in industrial electronics, automotive circuits, consumer electronics, and general purpose switching or amplification tasks. Its resistor-equipped configuration enables direct interfacing with digital logic outputs, streamlining circuit design and reducing component count.
