onsemi Schmitt Trigger Input Inverter 6 Elements 14-Pin TSSOP 2.0 to 5.5 V 74VHC14MTCX

Free Delivery in India | Lowest Global Shipping Charges

onsemi Schmitt Trigger Input Inverter 6 Elements 14-Pin TSSOP 2.0 to 5.5 V 74VHC14MTCX

Name: onsemi Schmitt Trigger Input Inverter 6 Elements 14-Pin TSSOP 2.0 to 5.5 V 74VHC14MTCX
Brand: onsemi
SKU: 129188



Category Inverters ICs Brand onsemi Condition New

Specifications

Country of Origin	India
Brand	onsemi
Height	900μm
Length	5mm
Model	74VHC14MTCX
Width	4.4mm
Mount Type	Surface
Compatibility	Input CMOS, Output CMOS
Output type	Bipolar Schottky TTL
Series	74VHC14
Input Type	Schmitt Trigger
Maximum Operating Temperature	85°C
Package Type	TSSOP
Minimum Operating Temperature	-40°C
Pin Count	14
Number of Elements per Chip	6
Maximum Supply Voltage	5.5V
Logic Family	VHC
Logic Function	Inverter
Minimum Supply Voltage	2V
Maximum High Level Output Current	-8mA
Maximum Propagation Delay Time @ CL	18.5ns
Maximum Low Level Output Current	8mA

Key Features

Features six inverter elements per chip with Schmitt trigger inputs for noise immunity.
Operates with a supply voltage range from 2 volts minimum to 5.5 volts maximum.
Maximum propagation delay time is 18.5 nanoseconds ensuring fast switching.
Output type is bipolar Schottky TTL compatible, with high-level output peak current of -8 mA and low-level output peak current of 8 mA.
Package is surface mount TSSOP with 14 pins and compact dimensions of 5 mm length by 4.4 mm width and 900 μm height.
Operating temperature range from -40°C to 85°C for industrial and commercial applications.
Compatible with CMOS logic levels on input and output for versatile circuit design.
Part of the 74VHC logic family with advanced high-speed CMOS technology ensuring low power consumption.

Product Description

onsemi 74VHC14MTCX is a six-element Schmitt trigger input inverter designed for high-speed CMOS logic applications operating at supply voltages from 2.0 V to 5.5 V. It utilizes advanced 74VHC family technology to offer fast switching speeds and low power consumption, making it suitable for industrial, commercial, and laboratory electronic circuit designs.

The device features six independent inverter gates each with Schmitt trigger inputs, providing high noise immunity and precise signal conditioning. The bipolar Schottky TTL compatible output supports a maximum high-level output current of -8 mA and a maximum low-level output current of 8 mA, making it compatible with a variety of logic circuits.

This component is supplied in a surface-mount 14-pin TSSOP package, measuring 5 mm in length, 4.4 mm in width, and 900 micrometers in height, optimizing board space and assembly efficiency.

Operating temperature ranges from -40°C to 85°C allow this inverter to withstand typical industrial environment conditions. Its compatibility with CMOS input and output logic levels extends its usability in mixed-logic systems.

Features six inverter elements with Schmitt trigger input for enhanced noise immunity. Wide operating voltage range between 2.0 V and 5.5 V for flexible power supply options. Fast maximum propagation delay of 18.5 ns supports high-speed digital operations.

Bipolar Schottky TTL output compatible with various logic families. Compact 14-pin TSSOP surface mount package suitable for automated PCB assembly. Robust operating temperature range from -40°C to 85°C fits industrial applications.

Advanced high-speed CMOS 74VHC technology ensures low power dissipation. Compatible with CMOS input and output logic levels.

This inverter IC finds applications in industrial automation systems, electronic instrumentation, telecommunications equipment, and other electronic designs requiring reliable logic inverters with Schmitt trigger inputs. It supports efficient PCB layout with its small package and surface mount capability.

Explore more logic IC solutions and semiconductor components in EnvMart’s extensive catalog to enhance your electronic product designs.

Explore more products in our Inverters ICs category.
