STMicroelectronics Surface Mount Shift Register TSSOP 16-Pin 4.5V to 5.5V Operating Voltage STPIC6C595TTR

STMicroelectronics STPIC6C595TTR is a surface mount shift register designed for reliable digital control applications. Housed in a compact TSSOP 16-pin package, the device supports a supply voltage range from 4.5V minimum up to 5.5V maximum. Its positive edge-trigger input makes it well suited for timing-sensitive electronic circuits. With a maximum operating temperature of 125°C, the device ensures stable performance even under elevated thermal conditions.

The shift register comprises a single element optimized for digital counting, data storage, and signal processing in semiconductor electronic designs. Its compact physical dimensions - 5.1mm in length, 4.48mm width, and 1.2mm height - allow it to fit in space-constrained PCB layouts efficiently. This component is primarily used in industrial automation, electronics manufacturing, and embedded systems requiring reliable sequential logic functions.

The product meets general semiconductor standards but does not hold specific automotive certifications. Its surface mount design supports automated assembly techniques, improving production throughput and consistency. STMicroelectronics offers full technical documentation including 3D models, schematics, and PCB footprints facilitating streamlined integration into various electronic designs.

Mount Type: Surface Mount TSSOP 16-pin package for compact PCB integration. Supply Voltage Range: 4.5V to 5.5V suitable for standard digital logic levels. Operating Temperature: Up to 125°C supports robust industrial environments.

Trigger Type: Positive edge trigger facilitates precise timing control. Dimensions: Length 5.1mm, Width 4.48mm, Height 1.2mm. Number of Elements: Single shift register element included. Series: STPIC6C595 series for compatibility in logic IC applications.

This semiconductor shift register is ideal for industrial automation, electronics prototyping, embedded system design, and digital control instrumentation. It supports efficient sequential logic operations in compact, surface-mounted form factors.
