STMicroelectronics 1-Element Bi-Directional TVS Diode Surface Mount 400 W, 2-Pin DO-214 SMAJ30CA-TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 2.03mm |
| Length | 4.6mm |
| Model | SMAJ30CA-TR |
| Width | 2.95mm |
| Mount Type | Surface |
| Series | SMAJxxCA |
| Maximum Operating Temperature | 150°C |
| Package Type | DO-214 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Clamping Voltage VC | 64.3V |
| Diode Configuration | Single |
| Direction Type | Bi-Directional |
| Minimum Breakdown Voltage Vbr | 33.3V |
| Maximum Reverse Stand-off Voltage Vwm | 30V |
| Peak Pulse Power Dissipation Pppm | 400W |
| Test Current It | 1mA |
| Maximum Peak Pulse Current Ippm | 36A |
| Maximum Reverse Leakage Current | 200nA |
Key Features
- Single diode configuration with bi-directional protection.
- Minimum breakdown voltage of 33.3 V ensures stable operation.
- Surface mount package DO-214 with compact dimensions.
- Peak pulse current rating of 36 A for robust transient voltage suppression.
- Clamping voltage of 64.3 V limits voltage spikes effectively.
- Operating temperature range from -55°C to 150°C for wide environmental tolerance.
- Low maximum reverse leakage current of 200 nA ensures low power loss.
- Designed for transient voltage suppression and ESD protection applications.
Product Description
STMicroelectronics SMAJ30CA-TR is a high-reliability 1-element bi-directional Transient Voltage Suppressor (TVS) diode designed for surface mounting on PCBs in a compact DO-214 package. This device offers a peak pulse power dissipation of 400 W and is suitable for protecting sensitive electronic circuits from voltage spikes and electrostatic discharge (ESD) events in industrial, automotive, and consumer electronics applications.
The diode configuration is single element, providing effective bidirectional voltage clamping capability with a minimum breakdown voltage of 33.3 V and a maximum reverse standoff voltage of 30 V. With a clamping voltage of 64.3 V and a peak pulse current of 36 A, it ensures transient overvoltages are absorbed efficiently, helping to maintain the integrity of critical components.
This TVS diode features low leakage current typically limited to 200 nA, minimizing standby power consumption. It operates reliably across a wide temperature range from -55°C to 150°C, making it ideal for harsh environments. The small DO-214 package footprint (4.6 mm length × 2.95 mm width × 2.03 mm height) supports dense PCB layouts.
The SMAJ30CA-TR series is widely used for transient and ESD protection in applications such as industrial control systems, power supplies, automotive electronics, and communication equipment. Its high surge current capacity and robust construction ensure long-lasting protection against transient voltage damages.
This product does not carry automotive-specific standards but meets general semiconductor quality demands for transient suppression applications. It is supplied on reels ready for automated assembly lines, enabling efficient mass production and improved manufacturing throughput.
Single diode configuration with bi-directional transient voltage suppression. 400 W peak pulse power dissipation in a compact surface mount package. Clamping voltage rating of 64.3 V for effective overvoltage protection.
Wide operating temperature range from -55°C to 150°C for industrial application suitability. Low leakage current minimizes power wastage in normal operation. Compact dimensions facilitate high-density PCB designs. Ideal for use in ESD and surge protection in electronic and automotive systems.
Supplied on tape and reel for automated manufacturing processes. Explore the Electronics & Electricals category for more semiconductor and TVS Diode solutions suitable for diverse industrial and commercial applications on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The peak pulse power dissipation of this model is 400 W, providing robust transient voltage suppression capabilities.
The clamping voltage for the SMAJ30CA-TR is 64.3 V, which effectively limits voltage spikes during transient events.
It operates reliably over a wide temperature range from -55°C to 150°C, making it suitable for harsh environments.
The maximum reverse stand-off voltage is 30 V, ensuring safe operation under normal conditions.
The maximum peak pulse current rating is 36 A, allowing it to handle significant transient surges.
The minimum breakdown voltage is 33.3 V, which ensures stable operation during transient events.
The dimensions of the DO-214 package are 4.6 mm in length, 2.95 mm in width, and 2.03 mm in height.
The maximum reverse leakage current is limited to 200 nA, which helps minimize power loss during operation.
This model features a single diode configuration, providing effective bi-directional voltage clamping.
It is suitable for applications involving transient voltage suppression and ESD protection in industrial, automotive, and consumer electronics.
The SMAJ30CA-TR is designed for surface mounting on PCBs, facilitating high-density layouts.
The country of origin for the SMAJ30CA-TR is India.
