TDK Film Capacitor 33 nF 700V AC 2 kV DC Through Hole Mount B32654A2333K000

Free Delivery in India | Lowest Global Shipping Charges

TDK Film Capacitor 33 nF 700V AC 2 kV DC Through Hole Mount B32654A2333K000



Category Film Capacitor Brand TDK Condition New

Specifications

Country of Origin	India
Brand	TDK
Height	23mm
Length	31.5mm
Model	B32654A2333K000
Width	13.5mm
Mount Type	Through Hole
Series	B32654
Maximum Operating Temperature	100°C
Capacitance	33nF
Standards/Approvals	UL, RoHS
Pin Count	2
Rated AC Voltage	700V ac
Rated DC Voltage	2kV dc
Lead Pitch	27.5mm
Lead Diameter	0.8mm
Automotive Standard	AEC-Q200 Rev D

Key Features

Rated AC voltage of 700V and DC voltage rating of 2 kV.
Constructed with wound capacitor technology and internal series connection for voltage ratings above 1250V DC.
Encapsulated in a UL 94 V-0 flame retardant plastic case sealed with epoxy resin.
Features high contact reliability and small compact dimensions.
Designed to operate at maximum temperature of 100°C.
Lead pitch measures 27.5 mm with lead diameter of 0.8 mm.
Pin count is 2 for through hole mounting.
Typical applications include TV S-correction, TV flyback, and electronic ballast circuits.

Product Description

TDK B32654A2333K000 film capacitor with a capacitance of 33 nF is designed for demanding electronics applications requiring reliable performance and safety. This through hole mounted capacitor is rated for an AC voltage of 700V and a DC voltage of 2 kV, making it suitable for high voltage circuits such as TV S-correction and flyback transformers as well as electronic ballast circuits.

The capacitor features wound capacitor technology with an internal series connection for high voltage rating and is housed in a robust flame retardant plastic case complying with UL 94 V-0 standards. The epoxy resin seal enhances durability and environmental resistance, enabling operation at temperatures up to 100°C.

With a lead pitch of 27.5 mm and lead diameter of 0.8 mm, it allows secure through hole mounting on printed circuit boards. The compact dimensions of 31.5 mm length, 13.5 mm width, and 23 mm height make this component suitable for space-constrained designs. Its high pulse strength and contact reliability ensure consistent operation in industrial and commercial electronics applications.

The B32654 series capacitor meets AEC-Q200 Rev D automotive standards as well as UL and RoHS approvals, underscoring its quality and compliance for automotive and industrial use. This product is manufactured in India, providing quality assurance and availability.

Rated AC voltage: 700V. Rated DC voltage: 2 kV. Capacitance: 33 nF. Maximum operating temperature: 100°C. Lead pitch: 27.5 mm. Lead diameter: 0.8 mm. Pin count: 2. Flame retardant plastic case UL 94 V-0. Epoxy resin sealing for durability.

Complies with AEC-Q200 Rev D automotive standard, UL, and RoHS.

This Film Capacitor is ideal for industrial electronic circuits including TVs, electronic ballast devices, and other high voltage AC/DC applications. Its compact size and reliable construction support use in precision electronic manufacturing, laboratory equipment, and automotive electronics.
