Samtec SLM Series Straight Through Hole PCB Socket 5-Contact 1 Row 1.27 mm Pitch Solder SLM-105-01-S-D
Specifications
| Country of Origin | India |
|---|---|
| Brand | Samtec |
| Orientation | Straight |
| Current | 5.2A |
| Model | SLM-105-01-S-D |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Bronze |
| Series | SLM |
| Termination | Through-hole |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 1 |
| Pitch | 1.27mm |
| Contact Plating | Gold |
| Number of Contacts | 5 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
| Contact System | Tiger Buy™ |
| Row Pitch | 2.54mm |
Key Features
- Constructed with polyester housing for high durability and insulation.
- Rated for 5.2A current capacity suitable for medium power applications.
- Contact material is bronze plated with gold for reliable conductivity and corrosion resistance.
- Designed for through-hole solder termination providing strong mechanical mounting.
- Supports operating temperature range from -55°C to 125°C for harsh industrial environments.
- Connector orientation is vertical and straight to facilitate easy PCB mounting.
- Row pitch of 2.54 mm complements the 1.27 mm pin pitch for precision alignment.
- Compatible with single or double row designs, supporting up to 100 pins.
Product Description
Samtec SLM-105-01-S-D is a high-quality straight through hole PCB socket designed for board-to-board connections. Featuring 5 female contacts in a single row configuration, this connector utilizes a 1.27 mm pitch to support precise and compact electronic layouts. Its polyester housing provides excellent mechanical strength and electrical insulation, making it suitable for demanding electronic applications.
The bronze contacts plated with gold ensure superior conductivity and durability, suitable for currents up to 5.2 amperes. Through-hole solder termination facilitates secure mounting on printed circuit boards, enhancing mechanical stability and long-term reliability under thermal cycling and vibration.
This PCB socket is engineered to operate in extreme temperature ranges from -55°C to 125°C, making it ideal for industrial, laboratory, manufacturing, and commercial electronics sectors. The vertical straight orientation and 2.54 mm row pitch further optimize installation accuracy in compact assemblies.
Samtec's proprietary Tiger Buy™ contact system integrated in this connector enhances mating performance, ensuring consistent and reliable electrical connections within the board-to-board connector system segment.
5-contact single row socket with 1.27 mm pitch. Polyester housing for durability and insulation. Gold-plated bronze female contacts rated at 5.2A current. Through-hole solder termination for robust PCB mounting. Wide operating temperature range from -55°C to 125°C.
Vertical straight orientation with 2.54 mm row pitch. Applicable in electronics manufacturing, industrial, and laboratory contexts. Compatible with designs up to 100 pins in single or double row formats. Part of the Samtec SLM series ensuring compliance with board-to-board standards.
Facilitates reliable, high-performance electronic connector solutions.
This connector is an excellent choice for engineers and technicians requiring durable, precise, and reliable PCB Sockets for advanced electronic assembly projects. Explore more Samtec SLM series connectors and related PCB components in the Electronics & Electricals category on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It has a current capacity rated at 5.2A, making it suitable for medium power applications.
The operating temperature range is from -55°C to 125°C, allowing it to function in harsh industrial environments.
This connector features 5 female contacts in a single row configuration.
It utilizes through-hole solder termination, providing secure mounting on printed circuit boards.
The housing is made of polyester for durability and insulation, while the contacts are bronze plated with gold for conductivity and corrosion resistance.
The contact pitch is 1.27 mm, which supports precise and compact electronic layouts.
The row pitch is 2.54 mm, which complements the 1.27 mm pin pitch for precision alignment.
It is part of a board-to-board connector system, designed for reliable connections between PCBs.
The orientation is vertical and straight, facilitating easy PCB mounting.
It is applicable in electronics manufacturing, industrial, and laboratory contexts.
It features Samtec's proprietary Tiger Buy™ contact system, enhancing mating performance and ensuring reliable electrical connections.
The country of origin for this product is India.
