DiodesZetex Small Signal Dual NPN and PNP Transistor 600 mA, 60 V, 6-Pin SOT-363 MMDT2227-7-F

DiodesZetex MMDT2227-7-F is a small signal dual NPN and PNP transistor designed for use in various electronic component applications including switching and amplification. Featuring a maximum continuous collector current of 600 mA and collector emitter voltage of 60 V, this transistor efficiently handles medium power applications in compact circuits.

The device is housed in a low-profile 6-pin SOT-363 surface mount package with compact dimensions (2.2 mm length, 2.2 mm width, 1.1 mm height), facilitating space optimization on printed circuit boards. It supports operation across a wide temperature range from -55 to 150 degrees Celsius, making it suitable for industrial, automotive, and other demanding environments.

The transistor configuration is isolated with combined NPN and PNP polarity, offering circuit designers flexibility for various switching and signal amplification tasks. The minimum DC current gain (hFE) is 35, providing suitable gain for small signal applications. Its maximum power dissipation rating of 200 mW ensures durability under typical operating conditions.

This device complies with automotive standard AEC-Q101, guaranteeing reliability and robustness for automotive electronic systems. The maximum collector base voltage rating is 75 V, and emitter base voltage is 6 V, further expanding its applicability.

Applications include electronic circuits requiring reliable switching, signal processing, and amplification within power and control modules. The device package and specifications make it ideal for compact and automotive electronics, telecommunications, and general industrial electronics.

Maximum DC collector current of 600 mA enables medium power switching applications. Collector emitter voltage rating of 60 V supports a wide range of circuit conditions. Surface mount package SOT-363 with 6 pins suitable for compact PCB designs.

Combined NPN and PNP transistor polarity allows versatile circuit configurations. Maximum power dissipation of 200 mW ensures reliable thermal performance. Operating temperature range from -55° to 150°C for industrial and automotive environments.

Minimum current gain (hFE) of 35 ensures adequate amplification in low signal circuits. Automotive compliant with AEC-Q101 standard for harsh condition suitability. Compact dimensions with length and width of 2.2 mm and height of 1.1 mm for space-saving applications.

Isolated transistor configuration minimizes interference in sensitive circuits. Explore more advanced semiconductor products and components in the Bipolar Transistors category on EnvMart for industrial, automotive, laboratory, and manufacturing applications.
