| Country of Origin | India |
|---|---|
| Brand | Vishay |
| Length | 3.7mm |
| Model | TZMB5V6-GS08 |
| Mount Type | Surface |
| Series | TZM |
| Maximum Operating Temperature | 175°C |
| Package Type | SOD-80 |
| Minimum Operating Temperature | -65°C |
| Standards/Approvals | RoHS |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 500mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 2μA |
| Nominal Zener Voltage Vz | 5.6V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 450Ω |
Vishay TZMB5V6-GS08 is a high-quality surface mount Zener diode designed for reliable voltage regulation applications in electronic circuits. It features a single diode configuration with a nominal Zener voltage of 5.6 V, rated to dissipate up to 500 mW of power.
The diode is housed in a compact SOD-80 package with 2 pins, optimized for surface mount technology (SMT) applications, providing ease of assembly and space saving on printed circuit boards. Its tight voltage tolerance of ±2% ensures precise voltage regulation in sensitive electronics.
This Zener diode supports a wide operating temperature range from -65°C to 175°C, making it suitable for automotive and industrial environments. It has a maximum reverse leakage current of 2 μA, a test current of 5 mA, and a maximum Zener impedance of 450 Ω, guaranteeing stable operation under varying loads.
The component complies with RoHS directives and the automotive standard AEC-Q101, certifying it for use in automotive electronic systems and demanding industrial applications. The diode is ideal for power management, voltage reference, and protection circuits in consumer electronics, industrial equipment, and automotive electronics.
Single diode configuration with 2 pins for surface mounting. Maximum power dissipation of 500 mW suitable for voltage regulation. Nominal Zener voltage rating of 5.6 V with ±2% tolerance. Package type SOD-80 offers compact surface mount compatibility.
Operating temperature range from -65°C to 175°C for reliable performance. Maximum reverse leakage current of 2 μA and test current of 5 mA. Maximum Zener impedance is 450 Ω ensuring stable voltage regulation. Compliance to RoHS and automotive standard AEC-Q101 certified.
Available for electronic design, manufacturing, and prototyping, this Vishay Zener diode TZMB5V6-GS08 supports various industrial, automotive, and laboratory electronics applications. Explore more quality semiconductor components in the Electronics & Electricals > Semiconductor > Zener Diodes category at EnvMart.
