| Country of Origin | India |
|---|---|
| Brand | Taiwan Semiconductor |
| Height | 0.95mm |
| Length | 3.05mm |
| Model | BAT54C RF |
| Width | 1.4mm |
| Mount Type | Surface |
| Series | BAT54 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 200mA |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Common Cathode |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 2μA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 600mA |
| Maximum Forward Voltage Vf | 1V |
| Peak Reverse Recovery Time trr | 5ns |
Taiwan Semiconductor BAT54C RF is a surface mount Schottky diode designed for efficient low power rectification and switching applications.
This 3-pin diode in a compact SOT-23 package offers a maximum continuous forward current of 200 mA and maximum reverse voltage of 30 V, making it suitable for a variety of electronic circuits requiring fast recovery and low forward voltage drop.
Featuring a common cathode configuration and peak reverse current of 2 μA, this diode ensures minimal leakage. Its maximum forward voltage of 1 V supports low power losses and enhanced energy efficiency.
The diode measures just 3.05 mm in length, 1.4 mm in width, and 0.95 mm in height, supporting miniaturized circuit designs. It withstands harsh environments with an operating temperature range from -55°C to 150°C and a peak surge current of 600 mA for transient conditions.
The BAT54C RF Schottky diode is ideal for use in industrial, consumer electronics, automotive, and communication equipment requiring reliable switching and power rectification. Maximum continuous forward current of 200 mA.
Peak reverse repetitive voltage of 30 V. Low forward voltage drop of 1 V for high efficiency. Compact SOT-23 package with 3 pins. Wide operating temperature range from -55°C to 150°C. Fast reverse recovery time of 5 ns. High surge current tolerance of 600 mA.
Common cathode diode configuration.
This product supports applications in electronics manufacturing, design, prototyping, repair, and maintenance workflows. Browse our semiconductor category for more reliable diode solutions.
Explore more products in our Schottky Diodes & Rectifiers category.
