Molex C-Grid III Series Right Angle Through Hole PCB Header 24 Contacts 2.54 mm Pitch 2 Row Shrouded 90130-3124
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 350V |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | C-Grid III |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Tin |
| Number of Contacts | 24 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Shrouded |
| Connector System | Wire-to-Board |
| Tail Pin Length | 2.9mm |
| Mating Pin Length | 6.75mm |
Key Features
- Constructed with brass contacts plated with tin for reliable conductivity.
- Housing made of durable polyester material ensuring long-term use.
- Rated for 3 amperes current carrying capacity at 350 volts.
- Operates reliably between temperatures of -55°C to 125°C.
- Right angle orientation suitable for wire-to-board connection via through-hole mount.
- Includes solder termination type with male contact gender and shrouded design for secure locking.
- Pin lengths include 2.9 mm tail pins and 6.75 mm mating pins for secure connections.
- Complies with standard electrical requirements without special certifications.
Product Description
Molex 90130-3124 C-Grid III Series Right Angle Through Hole PCB Header is a precision electronic component designed for robust wire-to-board interconnection applications.
This 24-contact connector features a 2.54 mm pitch arranged in two rows with a shrouded, right-angle design that facilitates secure mating with locking housings, preventing accidental disconnections.
The housing is made from high-quality polyester material, providing excellent mechanical strength and thermal resistance, allowing operation across a wide temperature range from -55°C to 125°C. Brass contacts plated with tin ensure optimal electrical conductivity and corrosion resistance.
The connector supports a current rating of 3A at up to 350 volts, making it suitable for various industrial and electronic equipment where reliable signal and power transmission is essential.
The through-hole mount and solder termination type enable lasting and stable PCB connections, with male contacts featuring a 2.9 mm tail pin length and 6.75 mm mating pin length for optimal engagement.
Brass contacts with tin plating ensure consistent conductivity and durability. Polyester housing provides mechanical robustness and thermal stability. Designed for wire-to-board applications using a through-hole mounting method.
Right angle and shrouded configuration enhances connection security. Operating temperature range supports harsh environments down to -55°C and up to 125°C. Rated for 3A current at 350V voltage, suitable for varied industrial uses.
Easy and secure solder termination for reliable PCB attachment. Complies with commonly used industrial electrical standards without additional certifications. This Molex PCB Header is ideal for use in electronic manufacturing, industrial control systems, telecommunications, and embedded systems requiring dependable PCB connections.
Explore related PCB connectors within EnvMart's Electronics Components category for comprehensive connectivity solutions.
