Molex 8-Way IDC Connector Female for Cable, 2 Row, 1.2A, 250V AC, Right Angle 90327-0360
Specifications
| Country of Origin | Ireland |
|---|---|
| Voltage | 250V ac |
| Brand | Molex |
| Orientation | Right Angle |
| Current | 1.2A |
| Mount Type | Cable |
| Housing Material | Polyethylene Terephthalate |
| Contact Material | Phosphor Bronze |
| Series | Picoflex |
| Termination Type | IDC |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -40°C |
| Number of Rows | 2 |
| Pitch | 1.27mm |
| Contact Plating | Tin over Nickel |
| Number of Contacts | 8 |
| Contact Gender | Female |
| Connector Gender | Female |
| Shrouded/Unshrouded | Unshrouded |
Key Features
- Features 8 contacts arranged in 2 rows for dense wiring requirements.
- Right angle orientation facilitates compact cable routing.
- Contact plating of tin over nickel ensures corrosion resistance.
- Housing made from Polyethylene Terephthalate providing durability and UL94V-0 flame rating.
- Operates reliably from -40°C up to 105°C for wide environmental tolerance.
- Unshrouded design for ease of IDC termination onto cables.
- Contacts fabricated from phosphor bronze for excellent conductivity and mechanical strength.
- Compatible with Molex Picoflex PF-50 Series and ideal for automotive and consumer electronics applications.
Product Description
Molex 90327-0360 8-Way IDC Connector Female is specifically designed for cable mounting applications requiring a compact 2-row arrangement. Rated for 1.2A current and 250V AC voltage, this connector provides reliable interconnection in industrial, automotive, and consumer electronic environments.
The right angle contact orientation enables efficient cable routing and space-saving designs. Constructed from phosphor bronze contacts plated with tin over nickel, it provides a durable and corrosion-resistant electrical connection. The housing material of polyethylene terephthalate meets UL94V-0 flame retardancy standards, ensuring safety and robustness.
Operating reliably over a temperature range from -40°C to 105°C, this connector supports harsh environmental conditions and industrial vibrations. Its unshrouded IDC termination simplifies cable assembly and ensures precise positioning of cables with a 1.27 mm pitch.
Part of the Picoflex series from Molex, this connector offers a 50% space saving compared with traditional pitch devices, enabling higher density system assemblies. It is widely used in automotive systems, consumer electronics, and other industrial applications requiring secure and compact wire-to-board interconnections.
Eight contacts in a double row configuration support dense wiring layouts. Durable phosphor bronze contact material with tin-nickel plating enhances electrical performance. Polyethylene terephthalate housing ensures flame retardant properties per UL94V-0.
Right angle orientation contributes to practical cable management in tight spaces. Wide operating temperature range for industrial and automotive applications. Unshrouded design allows easy IDC cable terminations. 50% space saving relative to traditional pitch connectors in the Picoflex series.
High shock and vibration resistance for rugged use cases. Manufactured in Ireland to high quality standards.
This Molex IDC connector provides a reliable and space-efficient solution for electrical wire-to-board connections across a variety of industrial, automotive, and electronic manufacturing needs. Browse our full range of IDC Connectors for complementary components and design support at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This connector is rated for a current of 1.2A and a voltage of 250V AC.
It operates reliably within a temperature range of -40°C to 105°C.
The housing is made from polyethylene terephthalate, while the contacts are fabricated from phosphor bronze with tin over nickel plating.
This model features 8 contacts arranged in 2 rows, facilitating dense wiring requirements.
It uses IDC (Insulation Displacement Connector) termination, which simplifies cable assembly.
Yes, it is widely used in automotive systems, as well as in consumer electronics and industrial applications.
The pitch of this connector is 1.27 mm, which supports compact arrangements in wiring.
This connector has a right angle orientation, which aids in efficient cable routing in tight spaces.
It is manufactured in Ireland to high quality standards.
This model has an unshrouded design that allows for easy IDC termination onto cables.
This connector is part of the Molex Picoflex series, which offers a space-saving design compared to traditional pitch devices.
The housing material meets UL94V-0 flame retardancy standards, ensuring safety in its application.
