Vishay High-Performance 100 V 5.5 A Surface Mount Schottky Rectifier TO-252 Package VS-50WQ10FN-M3
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 2.39mm |
| Brand | Vishay |
| Height | 2.39mm |
| Length | 6.73mm |
| Model | VS-50WQ10FN-M3 |
| Width | 6.22mm |
| Mount Type | Surface |
| Series | Q |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Standards/Approvals | AEC-Q101, RoHS 2002/95/EC |
| Pin Count | 3 |
| Automotive Standard | AEC-Q101 |
| Maximum Continuous Forward Current If | 5.5A |
| Peak Reverse Repetitive Voltage Vrrm | 100V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 1mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 330A |
| Maximum Forward Voltage Vf | 0.91V |
| Peak Reverse Recovery Time trr | 23ns |
Key Features
- This Schottky diode features fast switching with a low forward voltage drop.
- The device operates over a temperature range from -40°C to 150°C.
- TO-252 package with 3 pins facilitates surface mounting applications.
- Peak non-repetitive forward surge current of 330 A ensures high reliability under transient conditions.
- Complies with RoHS 2002/95/EC and AEC-Q101 automotive standards for quality and environmental safety.
- Peak reverse recovery time is approximately 23 nanoseconds for efficient switching.
- Suitable for automotive and industrial power conversion systems requiring low power loss rectification.
Product Description
Vishay VS-50WQ10FN-M3 is a high-performance Schottky rectifier diode designed for fast switching applications requiring low forward voltage drop and minimal reverse recovery time. It comes in a compact TO-252 surface mount package with three pins for efficient PCB assembly.
This rectifier supports a maximum continuous forward current of 5.5 A and a peak reverse repetitive voltage of 100 V, making it suitable for a wide range of power electronics applications. It features a peak reverse recovery time of 23 nanoseconds, allowing rapid switching with reduced power loss.
The device supports a minimum operating temperature of -40°C and a maximum of 150°C, ensuring reliable operation in harsh industrial and automotive environments. Its peak non-repetitive forward surge current rating of 330 A provides robustness to transient current spikes.
Compliant with AEC-Q101 automotive standards and RoHS directives, the VS-50WQ10FN-M3 is suitable for automotive power conversion circuits and renewable energy systems where durability and efficiency are critical.
Physical dimensions of the diode include a length of 6.73 mm, width of 6.22 mm, and height of 2.39 mm, with a total of 3 pins arranged in a DPAK (TO-252) configuration optimized for surface mounting.
Fast switching diodes with low forward voltage drop improve power efficiency. Complies with automotive standard AEC-Q101 ensuring quality and reliability. Wide operating temperature range from -40°C to 150°C supports automotive and industrial environments.
Compact TO-252 package suitable for surface mount applications. High surge current rating supports transient load conditions.
This Schottky rectifier is ideal for use in power supplies, battery chargers, solar inverters, and automotive electronics, where fast recovery and low conduction losses are essential. Explore more power semiconductors in the Vishay product range available at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current for this model is 5.5 A.
It operates over a temperature range from -40°C to 150°C.
This unit comes in a TO-252 package, suitable for surface mounting applications.
The peak non-repetitive forward surge current rating is 330 A.
The dimensions are 6.73 mm in length, 6.22 mm in width, and 2.39 mm in height.
It complies with the AEC-Q101 automotive standard.
The maximum forward voltage drop is 0.91 V.
Yes, it complies with RoHS 2002/95/EC standards for environmental safety.
This model has a single diode configuration.
