Wurth Elektronik WE-SL3 Surface Mount Common Mode Line Filter 22μH Dual Ferrite Core 700mA 9.2x6.6x2.5mm 744252220
Specifications
| Country of Origin | China |
|---|---|
| Brand | Wurth Elektronik |
| Height | 2.5mm |
| Length | 9.2mm |
| Depth | 6.6mm |
| Packaging | Tape & Reel |
| Series | WE-SL3 |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -40°C |
| Interfaces | USB, firewire, data and power lines |
| Core Material | Ferrite |
| Inductance | 22μH |
| Standards/Approvals | UL 94 V0 |
| Maximum DC Current | 700mA |
| Maximum DC Resistance | 140mΩ |
| Inductance Tolerance | -30 to 50 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 100kHz |
| Inductor Construction | Dual |
| Automotive Standard | AEC-Q200 |
Key Features
- This component features a surface mount design for easy PCB integration.
- Inductance tolerance ranges from -30 to +50% for reliable filtering performance.
- The filter has low DC resistance of 140mΩ to minimize power loss.
- It operates effectively within -40°C to 125°C temperature range.
- Compact dimensions of 9.2mm length, 6.6mm depth, and 2.5mm height ensure space-efficient assembly.
- Package supplied in tape and reel format suitable for automated production.
- Certified to automotive standard AEC-Q200 for quality and durability.
- Core material is ferrite, enabling high impedance up to 5000 Ω at 100kHz frequency.
Product Description
Wurth Elektronik model 744252220 is a Surface Mount Common Mode Line Filter designed with a dual ferrite core offering 22μH inductance with a wide tolerance of -30 to +50%. It supports a maximum DC current of 700mA and features a compact form factor measuring 9.2mm in length, 6.6mm in depth, and 2.5mm in height, making it suitable for space-constrained PCB layouts.
This line filter is terminated with a surface mount style and is packaged in tape and reel format to facilitate automated assembly in electronic manufacturing. It complies with the AEC-Q200 automotive standard, ensuring high reliability and performance in automotive and industrial applications.
The inductance is achieved using a ferrite core material that provides high impedance of up to 5000 Ω at a self-resonant frequency of 100kHz. Its operating temperature range from -40°C to 125°C makes it robust for harsh environments.
Engineered to reduce electromagnetic interference noise on CAN, USB, Firewire, data, and power lines, this filter is ideal for industrial, automotive, manufacturing, and electronics applications requiring effective EMI suppression.
This component features a surface mount design for easy PCB integration. Inductance tolerance ranges from -30 to +50% for reliable filtering performance. The filter has low DC resistance of 140mΩ to minimize power loss. It operates effectively within -40°C to 125°C temperature range.
Compact dimensions of 9.2mm length, 6.6mm depth, and 2.5mm height ensure space-efficient assembly. Package supplied in tape and reel format suitable for automated production. Certified to automotive standard AEC-Q200 for quality and durability.
Core material is ferrite, enabling high impedance up to 5000 Ω at 100kHz frequency. Applications include CAN, USB, Firewire, data, and power line noise filtering. Explore more Wurth Elektronik Surface Mount Inductors and common mode filters at EnvMart for advanced electronic component solutions.
