Vishay Schottky Diode 30 V 5.5 A 3-Pin DPAK Surface Mount TO-252 VS-50WQ03FN-M3
Specifications
| Country of Origin | India |
|---|---|
| Diameter | 2.39mm |
| Brand | Vishay |
| Height | 2.39mm |
| Length | 6.73mm |
| Model | VS-50WQ03FN-M3 |
| Width | 6.22mm |
| Mount Type | Surface |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-252 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Maximum Continuous Forward Current If | 5.5A |
| Peak Reverse Repetitive Voltage Vrrm | 30V |
| Diode Configuration | Single |
| Rectifier Type | Schottky |
| Peak Reverse Current Ir | 3mA |
| Peak Non-Repetitive Forward Surge Current Ifsm | 320A |
| Maximum Forward Voltage Vf | 0.35V |
| Vishay Diode, 50WQ03FNBrand | Vishay |
Key Features
- Surface mount device with TO-252 (DPAK) package is suitable for compact circuit designs.
- Low forward voltage drop of 0.35 V reduces power losses and improves efficiency.
- High surge current capability of 320 A peak non-repetitive forward surge.
- Operates reliably in temperatures ranging from -40°C to 150°C.
- Comes with 3 pins for secure mounting and easy soldering on PCBs.
- Schottky diode configuration delivers fast switching speed for power applications.
Product Description
Vishay VS-50WQ03FN-M3 is a high-performance Schottky diode designed for fast switching and low forward voltage drop applications. It supports a maximum continuous forward current of 5.5 A and peak reverse voltage of 30 V, making it ideal for power rectification in electronic circuits.
The device is packaged in a TO-252 (DPAK) surface mount package, facilitating space-efficient PCB layouts and reliable thermal management. With a low forward voltage drop of 0.35 V, it minimizes power dissipation, enhancing overall system efficiency.
This Schottky diode features a high surge current capacity up to 320 A, accommodating transient conditions safely. It operates over a wide temperature range from -40°C to 150°C, ensuring stable performance in industrial and commercial environments.
Physical dimensions include a length of 6.73 mm, width of 6.22 mm, and a height of 2.39 mm, suited for compact device assemblies. The device incorporates three pins designed for straightforward surface mounting and reliable soldering.
Applications for the Vishay VS-50WQ03FN-M3 range from power supply rectification, DC-DC converters, freewheeling diodes in motors, and other fast-switching semiconductor circuits within industrial, commercial, and electronic manufacturing settings.
Surface mount TO-252 package for compact design. Low forward voltage drop improves efficiency. High peak surge current handling capability. Wide operating temperature range for robustness. Three-pin configuration for easy PCB integration.
Suitable for fast switching and low power loss circuits. Compact dimensions compatible with modern electronics. Explore our Electronics & Electricals category for more Vishay semiconductor components and power rectifiers at EnvMart.
Explore more products in our Schottky Diodes & Rectifiers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum continuous forward current of the Vishay VS-50WQ03FN-M3 is 5.5 A.
This diode has a peak reverse voltage rating of 30 V.
The forward voltage drop is 0.35 V, which helps reduce power losses.
The diode can handle a peak non-repetitive forward surge current of 320 A.
It operates reliably in temperatures ranging from -40°C to 150°C.
The dimensions are 6.73 mm in length, 6.22 mm in width, and 2.39 mm in height.
This model is packaged in a TO-252 (DPAK) surface mount package.
It has a 3-pin configuration for secure mounting and easy soldering on PCBs.
This model is a Schottky diode, which is known for its fast switching speed.
It is suitable for applications such as power supply rectification, DC-DC converters, and freewheeling diodes in motors.
The peak reverse current is rated at 3 mA.
The country of origin for this diode is India.
